ACS510-01-03A3-4 Inverter Drive ABB 3ABD00015741-D

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

🔧 ABB ACS510-01-03A3-4 Inverter Drive Details

📋 General Information

Global Commercial Alias: ACS510-01-03A3-4

Product ID: 3ABD00015741-D

ABB Type Designation: ACS510-01-03A3-4

Catalog Description: ACS510-01-03A3-4, 3.3A, 380V, IP21

Product Net Weight: 6.1 kg

Product Dimensions:

  • Depth / Length: 465 mm
  • Height: 365 mm
  • Width: 225 mm

🔧 Technical Specifications

Number of Phases: 3

Degree of Protection: IP21

Enclosure Type NEMA: Type 1

Frequency: 47.5 ... 63 Hz

Frame Size: R1

Input Voltage (Uin): 380 – 480 V

Mounting Type: Wall-mounted

Output Current (Normal Use): 3.3 A

Output Power (Normal Use): 1.1 kW

Apparent Power Output: 2.3 kV·A

Efficiency Level: IE2

Standby Loss: 11 W

📊 Complete Drive Module Efficiency

Operating Point (Frequency / Current) Absolute Loss Relative Loss Efficiency
0 / 25 % 33 W 1.4 % 78.5 %
0 / 50 % 36 W 1.6 % 86.8 %
0 / 100 % 42 W 1.8 % 91.3 %
50 / 25 % 34 W 1.5 % 88.1 %
50 / 50 % 38 W 1.6 % 92.8 %
50 / 100 % 45 W 2 % 95.2 %
90 / 50 % 40 W 1.7 % 95.7 %
90 / 100 % 50 W 2.2 % 97 %

🌡️ Temperature Rating & Classifications

Temperature Rating: 40 °C

UNSPSC: 39122001
