Allen-Bradley 1791-0A16 Block I/O AC Output Module

Allen-Bradley 1791-0A16 Block I/O AC Output Module Overview

Key Technical Specifications

• Brand: Allen-Bradley
• Model: 1791-0A16
• Category: PLC Digital Output Module
• Output Channels: 16 AC Outputs
• Output Voltage Range: 20-132 VAC, 47-63 Hz
• On-State Current per Point: 50 mA minimum
• Output Delay (ON to OFF): 8.3 ms @ 60 Hz / 10.0 ms @ 50 Hz
• Output Delay (OFF to ON): 1.0 ms @ 60/50 Hz
• External Power Supply: 85-132 VAC, 47-63 Hz, 150 mA continuous
• Isolation Rating: 1250VAC between I/O groups and logic
• Wire Specification: Recommend 14 AWG stranded with max 3/64" insulation

Mounting & Installation Guidelines

• You can mount the module in either a vertical or horizontal orientation, but this affects the total current rating.
• For vertical mounting, the maximum output current is 600 mA at 30°C and 300 mA at 60°C ambient temperature.
• For horizontal mounting, the maximum output current is 300 mA at 30°C and 150 mA at 60°C ambient temperature.
• The module uses a removable terminal strip for easy wiring and module replacement.
• Always verify your device's voltage and current requirements before connecting them to the output channels.

Frequently Asked Questions (FAQ)

• Q: Do you have this module in stock ready to ship?
  A: Yes, the 1791-0A16 is available in our inventory for immediate order processing.
• Q: What is the output voltage and how many channels does it have?
  A: This is a 16-channel module with an output voltage range of 20-132VAC, nominally 120VAC.
• Q: Which Allen-Bradley PLC controllers work with this module?
  A: It is compatible with PLC-2, PLC-3, PLC-5/20, and PLC-5 series controllers.
• Q: What is the delay time when an output turns off?
  A: The OFF delay is approximately 8.3 milliseconds at 60 Hz power frequency.
• Q: What are the mounting options and do they affect performance?
  A: You can mount it vertically or horizontally. Vertical mounting provides a higher total current rating.
• Q: What is your shipping and return policy?
  A: We ship via DHL, FedEx, or UPS within 5 days and offer a 30-day return policy for your peace of mind.
