Allen-Bradley 1769-OB16P - 16-Channel Solid-State Output Module Key Specifications Part Number 1769-OB16P Output Type 16-channel solid-state (sourcing) Voltage Range 20.4-26.4VDC Current Rating 0.5A/channel @60°C, 1.0A/channel @30°C Switching Speed ON: 1ms, OFF: 2ms Technical Details Compatible Controllers CompactLogix, MicroLogix 1500 Power Consumption 160mA @5.1VDC Leakage...

Allen-Bradley 1769-OB8 8-Channel 24V DC Sourcing Output Module Output Specifications Output Type 8-channel sourcing (24V DC) Voltage Range 20.4 - 26.4V DC Current per Point 2A continuous Surge Current 4A for 10ms (repeatable every 2s) Power Consumption 145mA @5.1V DC System Configuration Compatible Controllers...

Allen-Bradley 1769-OG16 16-Channel TTL Output Module Key Features 16 TTL output channels 4.5-5.5V DC operating range 24mA max current per point Compact DIN rail mounting 0.15mA minimum load current Open-style enclosure Electrical Specifications On-State Voltage: 0-0.4V DC Off-State Voltage: 4.5-5.5V DC Undefined Range: 0.4-4.5V...

Allen-Bradley 1769-OV16 16-Channel Sinking Output Module Key Features 16-channel 24VDC sinking outputs High current capacity: 0.5A @ 60°C (1.0A @ 30°C) per point Fast switching: 0.1ms ON / 1.0ms OFF delay Removable terminal block with finger-safe cover Compact design saves panel space Technical Specifications...

🔑 Key Features Parameter Specification 🔌 Output Points 16 points, with relay isolation 🔋 Load Voltage/Current Ratings DC24V, 2A (resistive load)AC220V, 2A (with power factor COSφ = 1) 📉 Minimum Load DC5V, 1mA 📈 Maximum Load AC250V, DC125V ⚡ Leakage Current 0.1mA at AC220V,...

Allen-Bradley 1769-OV32T 32-Point 24V DC Sinking Output Module Key Features 32-point sinking outputs 24V DC solid-state design 10.2-26.4V operating range 2 groups of 16 points Copper wire (90°C/194°F) Open enclosure design Electrical Specifications Output Type 32-point sinking (24V DC) Voltage Range 10.2-26.4V DC Wire...

Allen-Bradley 1769-OB32T 32-Point 24V DC Sourcing Output Module Key Specifications Output Type 32-channel sourcing (24V DC) Voltage Range 10.2 - 26.4V DC Current Rating 0.5A per point (2A surge for 10ms) Switching Speed 0.5ms ON / 0.4ms OFF Power Consumption 220mA @5V DC (4.76W...

Overview The Triconex 3625 Digital Output Module is a reliable and robust 32-point output solution designed for industrial automation systems. It operates at a nominal voltage of 24VDC and features a state-of-the-art architecture to ensure high levels of safety and performance. This module is...

Technical Specifications Brand: Bently Nevada Model: 82365-01 Series: 3300 Dimensions: 2.0" x 9.0" x 4.0" (5.1 cm x 22.9 cm x 10.2 cm) Weight: 0.34 kg Input Types: Supports thermocouples (TC) and resistance temperature detectors (RTD) inputs (separate thermocouples and RTDs required) Channels: 6...

IC694MDL330 Electrical Performance Overview: Rated Voltage: 120/240 VAC Output Voltage Range: 85–264 VAC Rated Output Current: 2 A per point Maximum Inrush Current: 20 A for 1 cycle Output Frequency: 50/60 Hz Output Configuration: Total Output Points: 8 Group Division: 2 isolated groups of...

Overview The B&R AO775 Output Module is a part of the B&R System 2005 series, designed for applications requiring high-performance analog output capabilities. With its compact design and versatile output options, the AO775 module is ideal for integrating into automated systems where precise control...

1756-OV16E Electronically Fused Output Module MODULE HIGHLIGHTS 16-point sinking DC outputs Built-in electronic fusing protection 1A per point / 8A total current capacity Ultra-fast response: 75μs ON / 360μs OFF ELECTRICAL SPECIFICATIONS Voltage range: 10-30V DC Nominal rating: 24V DC operation Power dissipation: 6.72W...

GE Fanuc IC694MDL742 Output Module with ESCP Key Electrical Features Rated Voltage: 12–24 VDC Voltage Tolerance: –15% to +20% Outputs per Module: 16 (2 groups × 8) Output Current: 1 Amp max per point Inrush Current: 5.2 A for 10 ms Power Consumption: 130 mA (all outputs active) Protection...

GE Fanuc - Output Module IC694MDL740 Description: The 12/24 volt DC Positive Logic 0.5 Amp Output module, IC694MDL740, offers 16 output points divided into two groups of eight. Specifications: Rated Voltage: 12/24 volts DC Output Voltage Range: 12 to 24 volts DC (+20%, -15%)...

Technical Specifications Brand: GE FanucSeries: PACSystem RX3iPart Number: IC694MDL350 Output and Electrical Features Outputs per Module: 16 discrete outputsOutput Voltage Range: 74 – 265V AC (47 to 63 Hz)Nominal Output Voltage: 120/240 VACInrush Current: 20 Amps per cycleOutput Current: 2.0 A at 30°C, 1.0...

GE Fanuc IC693MDL350 Isolated Output Module Key Specifications Voltage Rating: 120 – 240 V AC Frequency: 50 – 60 Hz Inrush Current: 20 A per cycle Min. Load: 10 mA per point Output Response: < 10 ms Ambient Temp: –20 °C to 60 °C Storage Temp: –40 °C to 85 °C Humidity: 5 %–95 % RH (non‑condensing) MTBF: 100 000 hours Dimensions: 105 × 100 × 35 mm...

GE Fanuc IC693MDL731 8-Point 12-24VDC Discrete Transistor Output Module Technical Specifications Specification Details Brand GE Fanuc Series Series 90-30 Part Number IC693MDL731 Power Type DC Output Voltage Range 12 to 24 VDC Load Current per Point 2.0 Amps Response Time 2 ms (ON/OFF) Number...

📦 IC693MDL940 Relay Output Unit GE Fanuc Specifications Specifications Rated Voltage: 24 VDC, 120/240 VAC (nominal) Operating Voltage: 5 to 30 VDC; 5 to 250 VAC, 50/60 Hz Weight: 0.4 kg Performance Data Outputs per Module: 16 (four groups of four outputs) Maximum Load:...

GE Fanuc  - IC694MDL741 Negative‑Logic Output Module Core Specifications Channels: 16 (2 groups × 8) Voltage Range: 12–24 V DC (+20 / –15 % tolerance) Current: 0.5 A per channel, 2 A per group Isolation: 250 VAC continuous, 1500 VAC for 1 min (field↔backplane, group↔group, field↔frame) Response Time: 2 ms on/off Off‑State Leakage: ≤ 1 mA per channel Voltage Drop: ≤ 0.5 V...

Emerson Overview 📋 The KJ3208X1-BK1 is an S-Series digital output module designed for 8-channel 24 VDC isolated operations. It provides reliable digital output with robust isolation, making it suitable for various industrial applications where precision and durability are critical. Emerson Technical Specifications 🔧 Brand:...
