Allen-Bradley 2090-CFBM7DF-CEAA15 Feedback Cable

Allen-Bradley 2090-CFBM7DF-CEAA15 SpeedTEC Feedback Cable

The Allen-Bradley 2090-CFBM7DF-CEAA15 is a motor feedback cable designed for Bulletin 2090 servo systems. This 15-meter cable ensures accurate signal transmission from motor encoder to drive controller. It supports high-resolution feedback for precise motion control applications.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2090-CFBM7DF-CEAA15
• Series: Bulletin 2090
• Cable Type: SpeedTEC Feedback Cable
• Cable Function: Motor Feedback Only
• Cable Length: 15 Meters
• Flex Type: Standard (Non-Flex)

Connector Configuration

• Drive End: Flying-lead termination
• Motor End: SpeedTec DIN Connector
• Flying-lead design allows direct wiring to drive terminal blocks
• Standardized DIN connector provides secure motor interface

Encoder Compatibility

• Encoder Type: SIN/COS High-Resolution and Resolver Encoders
• Optimized for analog sine/cosine signal transmission
• Maintains signal integrity over the 15-meter distance
• Essential for closed-loop servo accuracy and stability

Application & Use

• Dedicated encoder feedback connection for Bulletin 2090 drives
• Ideal for applications requiring longer cable runs between motor and drive
• Suitable for fixed installations without continuous flexing motion
• Used in precision motion control systems across various industries

Installation Notes

• Connect the SpeedTec DIN connector securely to the motor's encoder port.
• Carefully terminate each flying-lead wire to the correct feedback input terminals on the 2090 drive, following the provided wiring diagram.
• Route the cable separately from power cables to prevent electrical noise interference.
• Use appropriate strain relief and cable management to support the longer 15-meter length.

Packaging & Shipping

• Package Includes: One 2090-CFBM7DF-CEAA15 feedback cable, 15 meters in length.
• Cable is coiled and packaged to prevent kinks and damage during transit.
• International shipping via FedEx, UPS, and DHL is available.

Frequently Asked Questions

• What is the length of this cable? This cable is 15 meters long, suitable for longer-distance installations.
• What does "motor feedback only" mean? It means this cable carries only the encoder signals, not motor power.
• What encoder types does it support? It supports SIN/COS high-resolution encoders and resolver-type encoders.
• Is this a flexible cable for cable carriers? No, it is a standard (non-flex) cable designed for fixed installations.
• What is the drive-end connection type? It has flying leads (individual wires) for connection to the drive's terminal blocks.
