Allen-Bradley 20F11NC043JA0NNNNN PowerFlex 753 Drive

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 20F11NC043JA0NNNNN AC Drive

The Allen-Bradley 20F11NC043JA0NNNNN is a compact AC drive from the PowerFlex 753 series. It delivers reliable 22 kW motor control with advanced features for precision and safety.

Product Overview & Key Features

  • Brand & Model: This is the Allen-Bradley 20F11NC043JA0NNNNN variable frequency drive.
  • Product Line: Part of the trusted PowerFlex 753 family.
  • Power Rating: Provides 22 kW of output power with a rated current of 43 Amperes.
  • Control Technology: Uses precise Sine Coded PWM control with a programmable carrier frequency.

Technical Specifications

  • Electrical Ratings: Input/Output: 400V AC / 540V DC, 3-phase. Frequency Tolerance: 47–63 Hz.
  • Cooling & Enclosure: Air-cooled design, typically in a Frame 6 open-type enclosure.
  • Protection Features: Comprehensive trip protection for over/under voltage, ground fault, short circuit, and overcurrent.
  • Built-in Components: Includes an input filter, internal braking transistor, and pre-installed CM jumper.
  • Environmental: Operates from 0 to 40°C; stores from -40 to 70°C (non-condensing). Weight: ~22.68 kg (50 lbs).

Installation & Operation

  • This drive is designed for panel mounting within a suitable industrial enclosure.
  • Connect the three-phase 400V AC power supply to the input terminals.
  • The sine-coded PWM ensures smooth motor operation and high efficiency.
  • Commissioning and control require an external Human Interface Module (HIM), sold separately.

Packaging & Shipping

  • The drive is shipped as a single, factory-assembled unit.
  • We deliver worldwide using reliable carriers FedEx, UPS, and DHL.

FAQ

  • What is the 20F11NC043JA0NNNNN? It is a 22kW, 400V AC drive from the Allen-Bradley PowerFlex 753 series.
  • What control method does it use? It employs advanced sine-coded Pulse Width Modulation (PWM).
  • Does it include a keypad? No, a separate Human Interface Module (HIM) is required for programming and monitoring.
  • What safety features are included? It has multiple protective trips for electrical faults to safeguard the drive and motor.
  • What is the default CM jumper for? It configures the common mode capacitor connection for reduced electrical noise.
