Allen-Bradley PowerFlex 753 VFD - Drive 20F1ANC140JN0NNNNN

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 20F1ANC140JN0NNNNN AC Drive

The Allen-Bradley 20F1ANC140JN0NNNNN is a versatile AC drive from the PowerFlex 753 series. It provides efficient motor control for a wide range of industrial automation applications.

Product Overview & Key Features

  • Brand & Model: This is the Allen-Bradley 20F1ANC140JN0NNNNN variable frequency drive.
  • Product Line: A reliable member of the PowerFlex 753 family.
  • Power Rating: Delivers up to 75 kW (140A) in normal duty and 55 kW for heavy-duty operation.
  • Design: An open-type, forced air-cooled packaged drive with integrated filtering.

Technical Specifications

  • Electrical Ratings: Input: 400V AC, 3-phase. DC Bus: 540V DC. Output Frequency: 0–500 Hz.
  • Enclosure: Open Type (IP20/IP00), designed for mounting inside a control panel.
  • Frame & Cooling: Built on a Frame 6 chassis with forced air cooling for effective heat dissipation.
  • Key Features: Includes AC input with pre-charge, a factory-installed common mode (CM) jumper, and protective conformal coating.
  • Weight: Weighs approximately 38.58 kg (85.06 lbs).

Installation Guide

  • Install this open-type drive inside a suitable industrial enclosure for protection.
  • Ensure adequate ventilation is provided for the forced air cooling system to operate effectively.
  • Connect the three-phase 400V AC power supply to the designated input terminals.
  • Use the integrated keypad or software tools to configure motor parameters and control logic.

Packaging & Shipping

  • The drive is shipped as a complete single unit in robust, protective packaging.
  • We manage global shipping through trusted carriers like FedEx, UPS, and DHL.
  • For this Frame 6 drive, standard freight services are typically used.

FAQ

  • What is the 20F1ANC140JN0NNNNN? It is a 75kW, 400V AC drive from the Allen-Bradley PowerFlex 753 series.
  • What is the output current? It has a maximum output current of 140 Amps.
  • What does "open type" mean? It has a basic enclosure (IP20/IP00) and must be installed inside a protective cabinet.
  • What cooling method does it use? It uses a forced air (fan) cooling system.
  • What is the conformal coating for? It provides an extra layer of protection against moisture, dust, and corrosive contaminants.
