AO820 ABB Analog Output Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

ABB AO820 Analog Output Module 4-Channel Bipolar

Technical Specifications

  • Number of Channels: 4
  • Resolution: 12-bit including sign
  • Output Load: ≤550 Ω (current), ≥5 kΩ (voltage)
  • Error: Max. 0.1% (voltage), Typ. 0.1% at 250 Ω, Max 0.15% (current)
  • Temperature Drift: Max 90 ppm/°C
  • Rise Time: <0.7 ms
  • Weight:0.22kg
  • Update Cycle Time: ≤1.5 ms
  • Short-Circuit Protection: Yes, current-limited output
  • Maximum Field Cable Length: 600 meters
  • Rated Insulation Voltage: 50 V
  • Dielectric Test Voltage: 500 V a.c.
  • Power Dissipation: Typ. 6 W

Diagnostics & Supervision

  • Continuous monitoring of output channels via ModuleBus.
  • Module Error: Low output power detected.
  • Channel Error: Open-circuit detection for currents >1 mA.
  • OSP function ensures outputs move to safe predetermined values on error.

FAQ

  • Is this module new? Yes, 100% original ABB product.
  • Does it support HART? No, HART not supported.
  • Maximum cable length? 600 meters
  • Can it be used in redundant MTU systems? No, single operation only.
