Bently Nevada 2300/20_KIT-003-00 Dual Sensor Kit

Dual-channel monitoring kit with two sensors

The Bently Nevada 2300/20_KIT-003-00 Condition Monitoring System Kit delivers complete dual-channel machinery protection. This 2300/20_KIT-003-00 package includes two accelerometers with 12 ft cables for flexible installation. Bently Nevada engineers this system for reliable 24/7 monitoring of two machine points.

Kit contents

• 2300/20 monitor with LCD display
• Two AM3100T2-Z2 accelerometer sensors with 12 ft (3.6 m) cables
• 6 ft (1.8 m) shielded Ethernet cable
• DIN rail adapter included for flexible mounting
• Ships via FedEx, UPS, or DHL

Key technical specifications

• Frequency range: 0.2 Hz to 20 kHz configurable bandpass filter
• Scale factor: 5 to 1000 mV/g for acceleration, 5 to 1000 mV/in/s for velocity
• Full scale: 2 to 80 g peak acceleration, 0 to 50 in/s peak velocity
• Radial vibration: 0 to 160 mil peak-peak with 5 to 1000 mV/mil scaling
• Accuracy: ±1% of full scale across all channels
• Independent 24-bit ADCs on each input channel
• RPM range: 1 to 120,000 for proximity transducers

Outputs and communication

• Two 4-20 mA outputs with internal loop power, 0 to 600 Ω load
• Two dry-contact relays: 6 A @ 250 Vac / 6 A @ 24 Vdc
• Three buffered BNC outputs for vibration and speed
• Ethernet 10Base-T/100Base-TX with RJ-45 connector
• Stores 5 alarm captures during network outages

Power and environmental

• Power input: 18 to 36 Vdc, max 7.5 W
• Operating temperature: -30°C to +65°C (-22°F to +149°F)
• Storage: -40°C to +85°C (-40°F to +185°F)
• Humidity: Up to 95% non-condensing
• Vibration limit: 3 g during operation

Dimensions and indicators

• Size: 76.2 mm x 127 mm x 127 mm (3 in x 5 in x 5 in)
• Weight: 1.03 kg (2.26 lbs)
• LCD shows machine speed, vibration, setpoints, and config
• LEDs for OK, fault, bypass, relay status, and channel alarm

Data capture

• Pre-event data: 10 minutes at 1 sec or 20 seconds at 100 ms
• Post-event data: 10 seconds at 100 ms or 1 minute at 1 sec
• Spectrum pre-event: 2.5 minutes at 10 sec intervals
• Spectrum post-event: 1 minute at 10 sec intervals

Frequently asked questions

What is the 2300/20_KIT-003-00?
The 2300/20_KIT-003-00 includes two accelerometer sensors with 12 ft cables. It uses the same 2300/20 monitor as other configurations but provides dual-channel input capability.

What sensors work with the 2300/20_KIT-003-00?
The 2300/20 accepts ICP accelerometers, Velomitor, Proximitor, and magnetic pickups. This kit includes two AM3100T2-Z2 accelerometers.

Can I use different cable lengths?
Yes. The monitor supports various cable lengths. Contact us if you need different cable options for your installation.

Do I need a separate power supply?
Yes. You need a 24 Vdc power supply (18-36 Vdc range). The kit excludes the power supply so you can select your preferred brand.

How do I mount the monitor?
The kit includes a DIN rail adapter. You can also panel mount it using the integral mounting points.
