Bently Nevada 330102-00-50-10-01-CN 8mm Probe

Bently Nevada 330102-00-50-10-01-CN 3300 XL 8 mm Probe

The Bently Nevada 330102-00-50-10-01-CN is a 3300 XL 8 mm proximity probe for rotating machinery monitoring. This probe features 3/8-24 UNF thread with armor, 0 mm unthreaded length, 50 mm overall case, and 1.0 metre cable with ClickLoc connector and CN agency approvals.

Technical Specifications

• Part Number: 330102-00-50-10-01-CN
• Model: 3300 XL 8 mm Probe
• Manufacturer: Bently Nevada

Suffix Code Configuration

• Model: 330102 - 3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor²
• Unthreaded Length: 00 - 0 mm
• Overall Case Length: 50 - 50 mm
• Total Length: 10 - 1.0 metre (3.3 feet)
• Connector & Cable: 01 - Miniature coaxial ClickLoc connector with connector protector, standard cable
• Agency Approval: CN

Physical Specifications

• Probe Diameter: 8 mm
• Mounting Thread: 3/8-24 UNF with armor
• Unthreaded Length: 0 mm
• Overall Case Length: 50 mm
• Total Cable Length: 1.0 metre (3.3 feet)
• Sensing Tip Material: Polyphenylene sulfide (PPS)
• Case Material: 300 series stainless steel
• Cable Type: Standard coaxial with armor
• Connector: Miniature coaxial ClickLoc with protective cap

Electrical Specifications

• Supply Voltage: -24 Vdc nominal
• Gap Range: 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Scale Factor: 7.87 mV/μm (200 mV/mil) typical
• Frequency Response: 0 to 10 kHz
• Linearity: ±1% over full temperature range
• Temperature Range: -35°C to +120°C (-31°F to +248°F)
• Pressure Rating: 2000 psi (138 bar) maximum

Agency Approvals

• CN: China-specific approvals

Key Features

• 8 mm diameter for standard mounting applications
• 3/8-24 UNF mounting thread with armor protection
• 0 mm unthreaded length for precise positioning
• 50 mm overall case length
• 1.0 metre (3.3 feet) total cable length
• Miniature coaxial ClickLoc connector with protective cap
• CN agency approvals for China market
• Armored cable for enhanced durability

Package Contents

• 1x Bently Nevada 330102-00-50-10-01-CN 3300 XL 8 mm Probe
• Connector protector installed
• Factory-sealed packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What is the full part number?
  330102-00-50-10-01-CN for 3300 XL 8 mm armored probe.
• What thread size is used?
  3/8-24 UNF with armor protection.
• What are the length options?
  0 mm unthreaded, 50 mm case, 1.0 metre total cable.
• What connector is included?
  Miniature coaxial ClickLoc connector with protector, standard cable.
• What agency approval is included?
  CN for China market.
• What is the temperature range?
  -35°C to +120°C (-31°F to +248°F).
