Bently Nevada 330130-030-03-05 Extension Cables

Overview

The Bently Nevada 330130-030-03-05 is a high-reliability 3300 XL 8mm Proximity Transducer System designed for precision vibration monitoring and machinery protection. Built in the U.S.A., it features a 3.0-meter armored cable with a connector protector, ensuring superior performance in demanding industrial conditions. This model is certified with CSA, ATEX, and IECEx approvals, making it suitable for hazardous environments. A Certificate of Origin (COO) is available upon request.

Technical Specifications

• Brand: Bently Nevada
• Model: 330130-030-03-05

Suffix Code Explanation:

• 030 → 3.0-meter (9.8 feet) cable length
• 03 → Armored cable with connector protector
• 05 → Certified with CSA, ATEX, and IECEx approvals

Electrical Characteristics:

• Power Requirements:
  • Without barriers: -17.5 Vdc to -26 Vdc at 12 mA max
  • With barriers: -23 Vdc to -26 Vdc (voltage above -23.5 Vdc may reduce linear range)
• Supply Sensitivity: Less than 2 mV change in output voltage per volt input variation
• Output Resistance: 50 Ω

Connector Type:

• Gold-plated, corrosion-resistant ClickLoc™ connectors
