Bently Nevada Velocity Sensor 330505-02-02-07

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (39 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

330505-02-02-07 Key Specifications

Sensitivity: 20 mV/mm/s (508 mV/in/s) ±10%

Frequency Response:

0.5 – 1000 Hz (30 – 60 000 cpm) ±3 dB

1 – 200 Hz (60 – 12 000 cpm) ±0.9 dB

Velocity Range: 102 mm/s (4 in/s) peak

Output Bias Voltage: –12 ± 1 VDC

Maximum Cable Length: 305 m (1000 ft) with no signal loss

Shock Survivability: 981 m/s² (100 g) peak

Operating Temp: –40 °C to +100 °C (–40 °F to +212 °F)

Relative Humidity: Up to 100% (non-submerged)

Weight: < 375 g (13.2 oz)

Insulation Resistance: > 100 MΩ @ 50 VDC

Noise Floor: 0.005 mm/s RMS

MTBF: 50 000 hours (est.)

Model Suffix Breakdown

330505 – Base model

-02 – Mounting angle: 90° ± 5°

-02 – Thread: 3/8-24 UNF-2B

-07 – Adapter: 3/8 – 16 UNC
