Bently Nevada Vibration Sensor Probe 330101-00-10-10-02-CN

A high-precision industrial sensor designed for vibration monitoring in extreme conditions. Combines rugged construction with patented TipLoc and CableLoc technology for unmatched reliability.

Configuration Options

• ➤ Unthreaded Length: 00 - 0.0 in (fully threaded)
• ➤ Case Length: 10 - 1.0 in (25.4 mm)
• ➤ Total Length: 10 - 1.0 m (3.3 ft) cable
• ➤ Connector: 02 - Miniature coaxial ClickLoc (IP67-rated)
• ➤ Agency Approval: CN - Country-specific certifications

Technical Highlights

• ➤ Thread Pitch: 3/8-24 UNF (9.525 mm major diameter)
• ➤ Cable Pull Strength: 330 N (75 lbf) retention force
• ➤ Coil Encapsulation: 8 mm PPS tip (20% thicker than standard 5 mm probes)
• ➤ Field Wiring: Supports 24 AWG to 1.5 mm² cables (305 m max length)
• ➤ Signal Stability: ±0.5% thermal drift (-30°C to +85°C)

Certified Performance

• ➤ EMC Compliance: EN 61326-1 (50 V/m RF immunity)
• ➤ Safety Rating: UL 61010-1 (300 V CAT II)
• ➤ Material Certifications: NACE MR0175 compliant
• ➤ Cycle Life: >10 million mechanical cycles
• ➤ MTBF: 250,000 hours (28+ years continuous operation)

Features FluidLock option for oil immersion applications (prevents fluid wicking). Compatible with all 3300 XL monitoring systems. Backward compatible with legacy Bently Nevada interfaces.
