Controller Module Allen-Bradley | 1762-L24BWAR

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
Only 10 units left
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

1762-L24BWAR Key Features

  • Inputs: 10 x 24V DC + 4 fast 24V DC digital inputs
  • Outputs: 10 x Relay outputs
  • Input Circuit Type: Sink/Source (selectable)
  • Input Power: 120–240V AC
  • Mounting: DIN Rail or Panel
  • Communication: RS-232 Programmer/HMI port (DH485 Full Duplex)

Electrical Specifications

  • Fast Inputs (0–3): Min. 2.5 mA @ 14V DC; Max. 12 mA @ 30V DC; Frequency: 0–20 Hz
  • Standard Inputs (4+): Min. 2 mA @ 10V DC; Nominal 8.9 mA @ 24V DC; Max. 12 mA @ 30V DC
  • Off-State Voltage: 0–5V DC
  • Off-State Leakage Current: Max. 1.5 mA
  • Sensor Supply: COM internally connected to chassis ground; only use for inputs

Physical Specifications

  • Dimensions: 90 mm (H) x 110 mm (W) x 87 mm (D) [3.5" x 4.33" x 3.43"]
  • Mounting Type: DIN Rail or Panel Mount
  • Operating Temperature: 0°C to 55°C (32°F to 131°F)
  • Weight: Approx. 2.0 lbs (0.9 kg)

Communication & Expansion

  • Port: RS-232 Mini-DIN (8-pin)
  • Supported Protocol: DH Full Duplex (receive-only mode)
  • Fixed Communication Settings: Cannot initiate messages; parameters not user-adjustable
  • Expandable I/O: Supports MicroLogix 1200 expansion modules
