Digital Input Module 1756-IV16 | Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Allen-Bradley

  • Type:

    Input Module

  • Tags Input module

About the Product

Allen-Bradley 1756-IV16 ControlLogix Digital Input Module

The 1756-IV16 from Rockwell Automation is a 16-point DC input module designed for ControlLogix systems. With group isolation (8 points/group) and flexible voltage operation (10-30V DC), it delivers reliable performance for industrial automation applications.

TECHNICAL SPECIFICATIONS

  • Brand: Allen-Bradley (Rockwell Automation)
  • Model: 1756-IV16
  • Input Type: 16-point DC sinking
  • Operating Voltage: 10-30V DC (Nominal 24V DC)
  • Input Current: 2mA @10V to 10mA @30V
  • Isolation: 250V continuous (8 points/group)
  • Response Time: Configurable 0-18ms filter
  • Power Consumption: 5.41W max @60°C

KEY FEATURES

  • High-density design: 16 inputs in single slot
  • Flexible filtering: User-selectable 0-18ms delay
  • Robust protection: 3.2kΩ input impedance
  • Wide voltage range: Operates from 10-30V DC

INSTALLATION

  • Terminal Blocks: Requires 1756-TBNH or 1756-TBSH
  • Chassis Compatibility: ControlLogix 1756 series
  • Backplane Current: 110mA @5V, 2mA @24V

TYPICAL APPLICATIONS

  • Machine control status monitoring
  • Conveyor system sensors
  • Safety interlock circuits

PACKAGE CONTENTS

  • 1756-IV16 module
  • Installation documentation

Available for worldwide shipping via FedEx, UPS, and DHL

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
