FANUC A02B-0029-K891 Connector Kit | Honda MR-50L 50-Pin

A02B-0029-K891 FANUC 50-Pin Connector Kit – A63L Contact Pins for CNC I/O

Technical Specifications

• Brand: FANUC
• Model: A02B-0029-K891
• Series: FANUC CNC accessory (order code family A02B-0029)
• Category: 50-pin female rectangular connector kit
• Connector Type: 50-pin female rectangular connector, Honda MR-50L style (supplier-reported)
• Included Contacts: A63L-0001 series contact pins (supplier-reported)
• Communication Interface: None (passive connector kit)
• Electrical Ratings: Not applicable; no rated parameters published
• Environmental Rating: Not applicable; no independent rating published
• Dimensions (H×W×D): Not applicable; no manufacturer outline dimensions
• Weight: ~0.05 kg (supplier-reported, family-level reference)
• Lifecycle Status: Legacy spare part; listed in aftermarket channels (Last verified: 2026-09)

Installation Guide

• Power down the CNC control and disconnect the main supply before you start.
• Check the connector kit for bent pins or cracked housings before installation.
• Strip the cable jacket to the length specified by your FANUC wiring diagram.
• Crimp each A63L-0001 contact pin onto the correct wire with a proper tool.
• Insert every crimped contact into the 50-pin housing until it locks in place.
• Confirm each contact sits at the same depth and no pin backs out.
• Mate the connector with its header and tighten the locking screws evenly.
• Power up the control and verify I/O signal continuity before production.

Packing List

• 1 × FANUC A02B-0029-K891 50-pin female connector housing
• 1 × Set of A63L-0001 series contact pins
• 1 × Anti-static protective bag
• 1 × Shock-absorbing foam insert
• 1 × Double-wall shipping carton

Shipping

• We ship worldwide through FedEx, UPS, and DHL.
• We dispatch in-stock items within 5 business days.
• We support returns within 30 days of delivery.

FAQ

• Q: Is the A02B-0029-K891 connector kit brand new and original?
  A: Yes, we supply brand new original units from our available stock.
• Q: Which connector style does this kit use?
  A: It uses a 50-pin female rectangular connector in the Honda MR-50L style.
• Q: Which contact pins come with the kit?
  A: The kit includes A63L-0001 series contact pins for the housing.
• Q: Does this connector kit have network or fieldbus support?
  A: No, it works as a passive connector kit with no network interface.
• Q: Are electrical ratings published for this kit?
  A: No, FANUC publishes no rated electrical parameters for this order code.
• Q: What is the approximate weight of the kit?
  A: Suppliers report a family-level reference weight of about 0.05 kg.
• Q: How long does shipping take?
  A: We ship in-stock items within 5 business days via DHL, FedEx, or UPS.
• Q: Can I return the kit if it does not fit?
  A: Yes, we accept returns within 30 days of delivery.
