FANUC A06B-6096-H106 1-Axis Amplifier | 230V Output

Introducing the FANUC A06B-6096-H106 Servo Amplifier

The FANUC A06B-6096-H106 is a high-power single-axis servo amplifier designed for precision CNC machine applications. This robust unit from FANUC delivers reliable performance for demanding industrial automation systems. It provides concentrated power output for critical motion control tasks in manufacturing environments.

Core Technical Specifications

• Brand: FANUC
• Model: A06B-6096-H106
• Product Type: Servo Amplifier
• Number of Axes: 1 Axis supported
• Rated Power: 9.1 kW output capacity
• Output Voltage: 230V standard output
• Input Voltage: 283-325V DC input range
• Operating Temperature: 0 to 40 degrees Celsius
• Vibration Tolerance: Maximum 5G vibration resistance
• Altitude Rating: Up to 1000 meters above sea level
• Approximate Dimensions: 11.9 x 14 x 3.3 Inches
• Unit Weight: 5.90 kg (13.00 lbs)

Performance and Environmental Features

• The FANUC A06B-6096-H106 withstands vibrations up to 5G maximum
• Rated for reliable operation at altitudes up to 1000 meters
• Operates effectively in temperature range 0 to 40°C ambient
• High power density with 9.1 kW single-axis output
• Compact dimensions for space-efficient cabinet installation
• Excellent thermal management for continuous operation

Installation and Application Details

• Specifically designed for CNC machine tool applications
• Ideal for high-power single-axis motion control systems
• Compact design: 11.9" x 14" x 3.3" for standard cabinets
• Compatible with 283-325V DC input power systems
• Manageable 5.90 kg weight simplifies installation
• Suitable for spindle drives and main axis applications

Electrical and Control Capabilities

• High power output of 9.1 kilowatts continuous
• Output voltage of 230V for standard motor drives
• Input voltage range of 283-325V DC
• Single-axis configuration for concentrated power delivery
• Stable voltage regulation under varying load conditions
• Excellent current control for precise torque output

Packaging and Delivery Information

• Includes one complete FANUC A06B-6096-H106 servo amplifier
• Professional industrial packaging ensures safe delivery
• Global shipping available via FedEx, UPS, or DHL carriers
• All necessary installation hardware and guides included

Frequently Asked Questions (FAQ)

• How many axes does it control?
  The A06B-6096-H106 controls 1 single axis.
• What is the power rating?
  This amplifier has a 9.1 kW power rating.
• What input voltage does it require?
  It operates on 283-325V DC input power.
• What is the output voltage?
  It delivers 230V output voltage.
• What environmental ratings does it have?
  Rated for 0-40°C, 5G vibration, 1000m altitude operation.
• What are its dimensions?
  Approximately 11.9 x 14 x 3.3 inches.
