FC-IOCHAS-0001R Redundant I/O Chassis Honeywell

Honeywell IOCHAS-0001R Redundant IO Chassis for Safety Manager

The FS-IOCHAS-0001R and FC-IOCHAS-0001R provide robust housing for redundant IO modules. This chassis supports high-availability systems with dual-processor control architecture.

Product Overview

• Redundant IO chassis for Safety Manager applications
• Supports up to 9 pairs of redundant IO modules
• 19-inch rack mount design for standard installation
• Includes IO housing, IO-0001 module, and blind front

Slot Configuration

• 21 total slots with 18 available for IO modules
• Slots 1-18 configured in redundant pairs
• Odd slots controlled by Control Processor 1
• Even slots controlled by Control Processor 2
• Slots 20-21 contain essential IO-0001 modules
• Slot 19 remains unavailable for use

Technical Specifications

• Models: FS-IOCHAS-0001R, FC-IOCHAS-0001R
• Power Consumption: 35mA on 5V-1 and 5V-2 supplies
• Rack Height: 4HE for additional chassis units
• Width: 482.6mm standard 19-inch rack
• Depth: 280mm for optimal space utilization
• Weight: 8.5kg robust construction

Physical Dimensions

• First Chassis: 44.5 + 133.4 + 44.5mm height
• Subsequent Chassis: 4HE uniform height
• Standard 19-inch width for rack compatibility
• Optimized 280mm depth for cabinet integration

Certifications & Compliance

• CE, UL, CSA, TUV, FM approved
• Meets international safety standards
• Industrial-grade construction for reliability
