About the Product

Honeywell FC-PSU-UNI12010U Industrial Power Supply

The FC-PSU-UNI12010U provides reliable 120V DC power for demanding industrial environments. This UL508 certified unit combines high efficiency with comprehensive safety features.

Key Features

  • Dual over-voltage protection meets strict functional safety standards
  • ON/OFF switch enables safe hot-swapping in live systems
  • Current limiting restricts maximum output to 1200 watts
  • DC under-voltage alarm activates below 108V threshold
  • Output diode allows flexible parallel operation setups
  • 100ms holdup time ensures continuous operation during interruptions

Technical Specifications

  • Model: FC-PSU-UNI12010U
  • Input Voltage: 110-240V AC (93-253V AC operating range)
  • Output Voltage: 120V DC stable output
  • Output Current: 10A from -5°C to +50°C
  • Power Rating: 1200W maximum output capacity
  • Efficiency: >85% at 220-240V AC input
  • Operating Temperature: -5°C to +70°C range
  • Storage Temperature: -25°C to +85°C

Electrical Performance

  • Wide input frequency range: 47-63Hz operation
  • Near-unity power factor for optimal efficiency
  • Low ripple and noise: <75mVpp for clean power
  • Derating begins at 50°C: 30W/°C reduction rate
  • Minimal no-load consumption: 13W maximum

Connection Interfaces

  • AC input: IEC 60320 C20 socket with 16A rating
  • DC output: Phoenix PCV4/3-G-7.62 with locking mechanism
  • Alarm contact: 3-pole Phoenix socket for monitoring
  • Isolated connectors ensure operational safety

Safety & Protection

  • UL508, CE, TUV, CSA certifications for global use
  • High isolation: 3750Vrms input to output protection
  • Comprehensive overload and short-circuit protection
  • Dual independent voltage regulation circuits

Physical Dimensions

  • Size: 420.5 × 140 × 90 mm (W × H × D)
  • Weight: 5.7 kg including cable set
  • Compact form factor for space-efficient installation
