GE 531X189LTBAJG1 Network Interface Card

GE 531X189LTBAJG1 VA-5 LAN Option Card

The GE 531X189LTBAJG1 is a VA-5 LAN Option Card manufactured by General Electric for industrial control systems.

Technical Specifications

• Part Number: 531X189LTBAJG1
• Product Type: VA-5 LAN Option Card
• Manufacturer: General Electric (GE)
• Condition: New, never used surplus
• Contactors: 8 yellow rectangular relays, Aromat DS2E-M-DC24V
• Male Ports: 6 ports for ribbon harness connections
• Jumper Ports: 7 ports, 3-prong, 2-position configuration
• Female Ports: 66 ports with screw terminals for cable securing
• Capacitors: 1 electrolytic capacitor
• Inductors: 3 inductors (coils/chokes/reactors) for energy storage
• Operating Voltage: 24 VDC for contactor coils
• Dimensions: 230 mm x 180 mm x 25 mm (9.1 in x 7.1 in x 1.0 in)
• Weight: 0.65 kg (1.43 lb)

Component Details

• Contactors: Aromat DS2E-M-DC24V, 2-pole, 24 VDC coil
• Contact Rating: 2 A at 30 VDC, 1 A at 125 VAC
• Inductor Value: 100 µH each, 1.5 A saturation current
• Capacitor Value: 470 µF, 35 VDC electrolytic
• Jumper Options: Address selection, termination enable, mode configuration
• Connector Type: IDC ribbon cable headers, 10-pin and 16-pin configurations

Key Features

• Provides LAN connectivity for GE control systems
• 8 onboard relays for signal switching and isolation
• 6 male ports for ribbon cable communication
• 66 screw-terminal female ports for field wiring
• 7 configurable jumper ports for flexible setup
• 3 inductors for power supply filtering
• Industrial grade components for reliability

Package Contents

• 1x GE 531X189LTBAJG1 VA-5 LAN Option Card
• Anti-static protective packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What is the function of this card?
  It provides LAN connectivity options for GE control systems to enable network communication.
• How many contactors does it have?
  8 yellow rectangular contactors rated 24 VDC, 2 A.
• What are the inductors used for?
  They store energy in magnetic fields for power supply filtering and noise suppression.
• How do I configure the jumpers?
  7 jumper ports with 2 positions each allow address and mode selection.
• What is the condition of this board?
  New, never used surplus in original factory condition.
