Description
xGE IS200ERBPG1ACA Exciter Regulator Backplane
System Integration & Architecture
- Central Control Hub: Facilitates connectivity between all mounted printed circuit boards
- Backplane Connectors: 3U/6U VME 96-pin and 128-pin DIN standards
- Communication Protocol: Board identification serial bus for all installed components
- Operation Modes: Master selection jumpers for simplex or redundant applications
- Modular Design: 13- or 21-slot VME card rack compatibility
Electrical Specifications
- Input Span: 4-20 mA standard industrial signal range
- Analog Output: 0-20 mA current output capability
- Common Mode Voltage: ±5 V operating range
- Lead Resistance: Maximum 15Ω for signal integrity
- Channel Capacity: 12 independent channels
Supported Board Modules
- IGBT (Insulated-Gate Bipolar Transistor) boards
- EPSM (Exciter Power Supply Module)
- ERDD (Exciter Regulator Interface and Dynamic Discharge)
- ERIO (Exciter Regulator Input/Output)
- ACLA (Application Control Layer)
- DSPX (Digital Signal Processor)
Communication & Interface
- Industrial Protocols: RS-485, Ethernet, Modbus compatibility
- SCADA Integration: Direct interface with monitoring systems
- Remote Control: Remote monitoring and parameter adjustment
- User Interface: Local configuration via touchscreen or keypad
- Data Acquisition: Integration with GE CIMPLICITY graphics platform
Environmental Specifications
- Operating Temperature: -30°C to +65°C industrial range
- Physical Dimensions: 8.26 cm height × 4.19 cm width/Weight:1.45kg
- Enclosure Design: Perforated casing for optimal airflow
- Mounting Features: Flanged edges with industrial mounting holes
- Cooling System: Rear-mounted airflow fan
System Identification & Configuration
- Board ID System: Programmed barcode serial numbers
- Hardware Tracking: Board type and revision information
- Slot Management: Individual control per backplane slot
- Revision Control: Three-fold product revision tracking
- Compatibility Database: Extensive component compatibility records
Application & Compatibility
- Turbine Control: Gas, steam, and wind turbine applications
- System Generation: Third-generation digital excitation scheme
- Retrofit Support: Stand-alone upgrade capability
- HMI Integration: Mark VI human-machine interface compatibility
- Manufacturing Origin: Salem, Virginia, USA factory production
Package Contents
- IS200ERBPG1ACA Backplane unit
- Installation documentation
- Technical specifications
- Integration guidelines
Warranty & Support
- 12-Month Warranty: Full manufacturer coverage
- Technical assistance services
- Quality certification
- Professional support network
