High-Performance PLC Processor TSXP574634M Schneider

Schneider Electric TSXP574634M Unity Processor

The TSXP574634M is a high-performance Unity processor from Schneider Electric for the Modicon Premium platform. This advanced controller delivers exceptional speed, memory, and connectivity for demanding industrial automation applications.

Technical Specifications

• Brand & Model: Schneider Electric TSXP574634M
• Product Type: Unity Processor for Modicon Premium PLC
• Software Platform: Programmed with Unity Pro software
• System Architecture: Supports up to 16 racks (4/6/8 slots) or 8 racks (12 slots)
• Total I/O Capacity: Up to 2040 discrete I/O and 256 analog I/O points
• Current Consumption: 1880 mA at 5 V DC from rack supply

Processing Power & Speed

• Boolean Execution: Ultra-fast 0.039-0.057 µs per instruction
• Floating Point: 0.55-0.63 µs per arithmetic operation
• Instruction Throughput: Up to 15.75 K instructions/ms (100% Boolean)
• System Overhead: Fast task: 0.08 ms, Master task: 1 ms
• Number of Tasks: 1 fast task, 1 master task, and 64 event tasks

Memory Configuration

• Internal RAM (without PCMCIA): 440 kB for program and data
• Internal RAM (with PCMCIA): 2048 kB program + 440 kB data
• PCMCIA Expansion: Adds 16384 kB (16 MB) additional data storage
• Object Areas: 32768 %Mi internal bits, 64 %KWi constant words, 64 %MWi internal words
• Unlimited unlocated internal data for function blocks and variables

Integrated Communication Ports

• Ethernet TCP/IP: RJ45 port, 10/100 Mbit/s, with full web services
• USB Port: High-speed 12 Mbit/s for programming and maintenance
• Serial Link: Mini-DIN RS485 port at 19.2 kbit/s for legacy devices
• Transparent Ready: Class B30 web server for remote monitoring
• Communication Capacity: Supports multiple communication modules

Advanced Control Features

• Process Control: Handles 20 to 60 simple control loops
• Application Channels: 64 dedicated channels for specific functions
• Discrete Capacity: Manages large systems with up to 2040 I/O points
• Analog Capacity: Controls up to 256 analog I/O signals

Status Indicators & LEDs

• RUN LED (Green): Processor running status
• ERR LED (Red): Processor or system fault
• I/O LED (Red): Module or configuration fault
• RUN LED (Green): Ethernet port ready
• ERR LED (Red): Ethernet port fault
• Multiple Yellow LEDs: Network activity, collision detection, serial port activity

Environmental Specifications

• Operating Temperature: 0 to 60 °C (32 to 140 °F)
• Storage Temperature: -25 to 70 °C (-13 to 158 °F)
• Humidity Range: 10-95% non-condensing for operation
• Operating Altitude: Up to 2000 meters (6562 feet)
• Protection Rating: IP20 enclosure, Pollution Degree 2
• Protective Treatment: TC specification for industrial use

Certifications & Standards

• Compliant with UL 508, IEC 61131-2, and CSA standards
• CSA Class I Division 2 Groups A, B, C, D for hazardous locations
• CE marked for European market requirements
• Marine certifications: BV, RMRS, ABS, RINA, LR, DNV, GL

Physical Specifications

• Module Format: Double-width module for TSX Premium racks
• Net Weight: 0.61 kg (1.34 lb)
• Designed for standard TSX Micro/Premium rack installation

Packaging & Shipping

• The TSXP574634M processor ships as one complete unit.
• Includes the processor module ready for rack installation.
• Protected in secure industrial packaging.
• Worldwide express shipping via FedEx, UPS, and DHL available.

Frequently Asked Questions (FAQ)

• What is a Unity processor? It is the central CPU for Schneider Electric's Modicon Premium PLC platform, programmed with Unity Pro software.
• How many I/O points can it handle? It can manage large systems with up to 2040 digital and 256 analog I/O points.
• What communication ports are built-in? It includes Ethernet, USB, and RS485 serial ports for connectivity.
• Does it support remote access? Yes, the integrated Transparent Ready web server allows remote monitoring via a web browser.
• Can I expand the memory? Yes, using a standard PCMCIA memory card, you can add 16 MB of storage.
• What is the execution speed? It executes Boolean instructions in under 0.06 microseconds, making it suitable for high-speed control.
• Is it compatible with existing TSX racks? Yes, it uses the double module format for TSX Micro/Premium PLC racks.
