Honeywell MLE-RY16A 16-Channel Relay Output

Honeywell MLE-RY16A Relay Output Module

The MLE-RY16A is a 16-channel Relay Output module from Honeywell. It provides electromechanical relay outputs for switching AC/DC loads in industrial control applications.

Technical Specifications

• Brand & Model: Honeywell MLE-RY16A
• Product Type: Relay Output Module
• Channels: 16 relay outputs
• Contact Rating: 2A @ 24V DC or 220V AC
• Response Time: ON ≤10 ms, OFF ≤12 ms
• Switching Rate: 3600 times/hour max

Electrical Characteristics

• Max Load Voltage: AC 250V, DC 125V
• Min Load: DC 5V @ 1mA
• Leakage Current: ≤0.1 mA @ AC 220V, 60Hz
• Current per COM: 5A maximum total

Relay Life Expectancy

• Mechanical Life: 20 million operations
• Electrical Life:
  • 100,000+ operations at rated load
  • Reduced life for inductive/capacitive loads

System Integration

• Common Method: 8 point / 1 COM (2 groups of 8)
• Connectors: 2 x 9-pin terminal blocks
• Indicator: LED per output for ON status
• Power Consumption: 420 mA internal
• Weight: 160 g

Key Features

• AC/DC load switching capability
• High mechanical life (20M operations)
• LED status indication per channel
• Industrial relay contacts
• Grouped common terminals

Typical Applications

• Motor starter control
• Solenoid valve operation
• Heater and lighting control
• General purpose switching

Packaging & Shipping

• New unit in factory packaging
• Worldwide shipping via FedEx, UPS, DHL

FAQ

• Contact rating? 2A @ 24V DC or 220V AC resistive load.
• Relay life? 20 million mechanical, 100,000+ electrical operations.
• Common grouping? 2 groups of 8 channels with separate commons.
• Response time? ON ≤10ms, OFF ≤12ms typical.
• Connectors? Two 9-pin terminal blocks for connections.
