Honeywell MLF-AD08A Analog Input Module 8 Channel

Honeywell MLF-AD08A Analog Input Module

The MLF-AD08A is an 8-channel Analog Input module from Honeywell. It accepts both voltage and current signals for process measurement applications with high-speed conversion capability.

Technical Specifications

• Brand & Model: Honeywell MLF-AD08A
• Product Type: Analog Input Module
• Channels: 8 analog inputs
• Signal Types: Voltage (0-10V, 0-5V, 1-5V) and Current (4-20mA, 0-20mA)
• Resolution: 12-bit binary
• Conversion Speed: 1.5 ms per channel

Input Specifications

• Voltage Inputs:
  • 0-10V, 0-5V, 1-5V
  • Input Resistance: ≥250 MΩ
• Current Inputs:
  • 4-20mA, 0-20mA
  • Input Resistance: 250 Ω
• Absolute Maximum: ±15V, ±25mA

Digital Output Values

• Unsigned: 0-4000
• Signed: -2000 to 2000
• Precise: Scaled to engineering units
• Percentile: 0-1000 for voltage inputs

System Integration

• Insulation: Photo-coupler isolation
• Terminal: 11-point terminal block
• Points Occupied: Fixed 64-point assignment
• Power Consumption: 5V @ 105mA, 24V @ 85mA
• Weight: 70 g

Key Features

• Dual signal type support
• High 12-bit resolution
• Fast 1.5 ms per channel conversion
• Electrical isolation protection
• Compact lightweight design

Typical Applications

• Process variable monitoring
• Sensor signal acquisition
• Temperature/pressure measurement
• Flow and level monitoring

Packaging & Shipping

• New unit in factory packaging
• Worldwide shipping via FedEx, UPS, DHL

FAQ

• Signal types? Accepts both voltage (0-10V) and current (4-20mA) signals.
• Resolution? 12-bit resolution for precise measurement.
• Conversion speed? Fast 1.5ms per channel conversion.
• Isolation? Photo-coupler isolation between I/O and power.
• Terminal block? 11-point terminal block for connections.
