Honeywell MLF-DC04A 4-Channel Analog Output

Honeywell MLF-DC04A Analog Output Module

The MLF-DC04A is a 4-channel Analog Output module from Honeywell. It provides current output signals for controlling process actuators with reliable performance and good accuracy.

Technical Specifications

• Brand & Model: Honeywell MLF-DC04A
• Product Type: Analog Output Module
• Channels: 4 current outputs
• Output Ranges: 4-20mA, 0-20mA
• Accuracy: ±0.5% maximum error
• Conversion Speed: 1.0 ms per channel
• Max Load: ≤510 Ω

Output Specifications

• Current Ranges:
  • 4-20mA standard industrial
  • 0-20mA extended range
• Resolution: 5 μA (1/4000 of range)
• Absolute Maximum: ±25 mA
• Data Formats:
  • Unsigned: 0-4000
  • Signed: -2000 to 2000
  • Precise: 400-2000 (4-20mA), 0-2000 (0-20mA)
  • Percentile: 0-1000

System Integration

• Isolation: Photo-coupler (terminal to power, no channel-channel)
• Terminal: 11-point terminal block
• Points Occupied: Fixed 64-point assignment
• Power Consumption: 5V @ 110mA, 24V @ 120mA
• Weight: 124 g

Key Features

• Good ±0.5% accuracy
• Fast 1 ms per channel update
• Dual output range support
• Electrical isolation protection
• Flexible data format selection

Typical Applications

• Control valve positioning
• Variable speed drive control
• Process setpoint output
• Current loop device interface

Packaging & Shipping

• New unit in factory packaging
• Worldwide shipping via FedEx, UPS, DHL

FAQ

• Output type? Current output (4-20mA or 0-20mA).
• Accuracy level? ±0.5% maximum error.
• Load limit? Maximum 510 Ω load resistance.
• Update speed? Fast 1ms per channel update rate.
• Data formats? Multiple formats selectable via user program.
