K-D M8W-4P-10m-PVC Leuze 4-Pin Sensor Cable | 10 Meter

Leuze M8 Sensor Cable: 4-Pin, 10m Length

Connect your sensors with this reliable 10-meter cable from Leuze. It has a sturdy M8 connector with 4 pins. The PVC cable is made for factory use. It handles tough conditions very well.

Why Choose This Leuze M8A-4P-10m-PVC Cable?

• Long Reach: 10-meter length gives you more setup freedom.
• Secure Fit: Screw lock stops vibrations from loosening the connection.
• All-Weather Cable: Works in very cold and hot temperatures.
• Easy to Install: Just plug in and tighten the screw collar.

Product Specifications

Brand & Model: Leuze K-D M8A-4P-10m-PVC

Full Model Info: K-D Series, M8 Axial Connector, 4 Pins, 10m length, PVC Jacket.

Electrical Info:

Max Voltage: 60V AC or DC

Max Current: 4 Amps per pin

Safety Rating: Category I (IEC 60664-1)

Cable & Connector Info:

Wire Size: 0.25 mm²

Cable Thickness: 4.2 to 4.9 mm

Min Bend: At least 10x cable thickness

Connector Material: Nickel-plated zinc

Lock Type: Screw lock (Hand-tighten to 0.6 Nm)

Environment:

Temp Range (Fixed): -30°C to +70°C

Temp Range (Moving): -5°C to +70°C

Cable Color: Black

FAQs for Leuze M8A-4P-10m-PVC Cable

Q1: What devices work with this cable?

A1: It works with many 4-pin M8 sensors. This includes certain photoelectric sensors, inductive sensors, and valve connectors from Leuze and other brands. Always check your device manual.

Q2: Is the 10m length good for signal quality?

A2: Yes, for standard sensor signals at 60V/4A, 10 meters is fine. For very high-speed data, check your device limits. Use good cable routing.

Q3: How do I make sure it's sealed properly?

A3: Hand-tighten the screw collar until it stops. Do not use tools to force it tighter. This compresses the seal and makes it weatherproof.

Q4: Can I use it outside or in wet areas?

A4: The PVC jacket resists water, oil, and dust. It is good for damp indoor areas. For full outdoor or washdown use, a cable with a higher IP rating may be better.

Q5: My cable got very cold. Is it damaged?

A5: If it was fixed in place, it can handle down to -30°C. If you were moving it in the cold, keep it above -5°C. Let it warm up slowly before flexing to avoid cracking.

What You Get & Support

Package Includes: 1 x Leuze K-D M8A-4P-10m-PVC connection cable.

Shipping: We ship quickly with FedEx, UPS, or DHL.

Your Guarantee: We offer a full 12-month warranty from your purchase date.
