MLF-AD04C 4-Channel Analog Input by Honeywell

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (22 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Honeywell

  • Type:

    I/O Module

  • Tags I/o module

About the Product

Honeywell MLF-AD04C High Voltage Analog Input Module

The MLF-AD04C is a 4-channel High Voltage Analog Input module from Honeywell. It supports wide voltage ranges including ±10V for industrial measurement applications with high resolution.

Technical Specifications

  • Brand & Model: Honeywell MLF-AD04C
  • Product Type: High Voltage Analog Input Module
  • Channels: 4 analog inputs
  • Voltage Ranges: 0-10V, ±10V, 0-5V, 1-5V
  • Current Ranges: 4-20mA, 0-20mA
  • Resolution: 14-bit effective (16-bit format)
  • Conversion Speed: 1.0 ms per channel

Input Specifications

  • Voltage Inputs:
    • 0-10V, ±10V, 0-5V, 1-5V
    • Input Resistance: ≥1 MΩ
  • Current Inputs:
    • 4-20mA, 0-20mA
    • Input Resistance: 250 Ω
  • Absolute Maximum: ±15V, ±30mA

Digital Output Values

  • Unsigned: 0-16000
  • Signed: -8000 to 8000
  • Precise: Scaled engineering values
  • Percentile: 0-10000

System Integration

  • Isolation: Photo-coupler (terminal to power, no channel-channel)
  • Terminal: 15-point terminal block
  • Points Occupied: Fixed 64-point assignment
  • Power Consumption: 5V @ 110mA, 24V @ 100mA
  • Weight: 120 g

Key Features

  • Wide ±10V voltage range support
  • High 14-bit effective resolution
  • Fast 1 ms per channel conversion
  • Dual signal type capability
  • Industrial isolation protection

Typical Applications

  • High voltage signal measurement
  • Process control monitoring
  • Test and measurement systems
  • Industrial sensor interfacing

Packaging & Shipping

  • New unit in factory packaging
  • Worldwide shipping via FedEx, UPS, DHL

FAQ

  • Voltage range? Supports up to ±10V for high voltage signals.
  • Resolution? 14-bit effective resolution (16-bit data format).
  • Conversion speed? Fast 1ms per channel sampling.
  • Isolation? Photo-coupler isolation (no isolation between channels).
  • Terminal block? 15-point terminal block for connections.
