PC-E984-285C Compact Controller | Schneider Modicon

Introducing the Schneider Electric PC-E984-285C Compact Controller

The PC-E984-285C is a versatile compact controller for Modicon automation systems. This unit combines substantial memory capacity with flexible I/O options. It features PROFIBUS-DP communication for seamless industrial network integration.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric PC-E984-285C
• Logic Memory: Provides 32 K of logic memory for program storage
• Data Memory: Features 64 K of data memory for variable storage
• Processing Speed: Operates at 12 MHz clock frequency for efficient execution
• Digital I/O Capacity: Manages 256 digital I/O points for device connectivity
• Power Supply: Requires standard 24 VDC input voltage
• Communication Protocol: Integrated PROFIBUS-DP interface for industrial networking
• Controller Weight: Lightweight design at 0.69 lbs (0.31 kg)

Robust Design & Operating Environment

• Operating Temperature: Functions reliably from 0°C to 55°C
• Mounting Type: Standard DIN rail mounting for easy installation
• Protection Rating: IP20 enclosure protects against dust and contact
• Humidity Range: Operates at 5% to 95% relative humidity without condensation
• Package Dimensions: 10.4" L x 7.09" W x 4.1" H (26.5 x 18 x 10.5 cm)
• Shipping Weight: Package weighs 29.7 oz (841 g)

Packaging & Shipping Information

• Package Includes: One (1) PC-E984-285C compact controller unit
• Shipping Methods: International shipping via FedEx, UPS, and DHL
• Country of Origin: Manufactured in Germany
• Product Category: Compact 984 Controllers for industrial automation

Installation & Integration Guide

• Mount this compact controller on a standard DIN rail in your control panel
• Connect 24 VDC power supply to the designated input terminals
• Wire your digital devices to the 256 available I/O points
• Connect to PROFIBUS-DP networks using the integrated communication port
• Program the controller using the 32K logic memory for your application
• Utilize the 64K data memory for storing process variables and parameters
