PM 904F ABB-3BDH001002R0001 CPU Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

📋 Technical Specifications

Processor & Memory

Total RAM: 48 MB (16 MB battery-buffered)
CPU Clock Speed: 800 MHz

I/O Capability

Direct I/O Modules: Up to 10 modules

Power Requirements

Power Consumption: 24 W (full assembly)
Supply Voltage: 24 VDC
Max Power Dissipation: 18 W
Current Draw: 1 A
Inrush Current: 1.5 A

Battery Backup

Backup Source: Lithium battery
Buffering Time: >2 years at 40°C, with a 14-day warning period before critical battery status

Communication Ports

Serial Ports (SER1 & SER2): RS-232/RS-485 (600 bps - 38400 bps), with pluggable terminal blocks for Modbus RTU and IEC 60870-5-101 Telecontrol.
Ethernet Ports (4x RJ45):
- Ethernet 1 & 2: For ControlNet, Modbus TCP, IEC 60870-5-104, and redundancy link
- Ethernet 3 & 4: Support ControlNet redundancy or Modbus TCP/IEC 60870-5-104

Physical Attributes

Weight: 1.1 kg (2.43 lbs)
Dimensions: 285 mm (W) x 152 mm (H) x 95 mm (D)
