PowerFlex 753 AC Drive Allen-Bradley 20F11NC072JA0NNNNN

Introducing the Allen-Bradley 20F11NC072JA0NNNNN PowerFlex 753 AC Drive

The Allen-Bradley 20F11NC072JA0NNNNN is a robust variable frequency AC drive from the PowerFlex 753 series, engineered for precise motor control in industrial applications. This reliable drive from Allen-Bradley delivers efficient power conversion and flexible configuration options for automation systems. It provides advanced control features and reliable performance in various manufacturing environments.

Core Technical Specifications

• Brand: Allen-Bradley
• Model: 20F11NC072JA0NNNNN
• Product Type: Variable Frequency AC Drive
• Product Line: PowerFlex 753
• Power Rating (Normal Duty): 37 kW
• Rated Current: 72 Amps
• Voltage Class: 400V AC / 540V DC
• Phase: 3-phase input
• Frame Size: Frame 4 construction
• Cooling Method: Air Cooled
• Mounting Orientation: Vertical panel mount
• Enclosure Type: Open type design
• Embedded I/O: Included for basic control
• Dynamic Braking Transistor: Yes, included
• Dynamic Braking Resistor: Not included
• CM Jumper: Installed
• Option Slots: 3 available (safety, feedback, communication)
• Unit Weight: 27.22 kg (60.00 lbs)

Performance and Control Features

• The Allen-Bradley 20F11NC072JA0NNNNN delivers 37 kW normal duty power
• High current capacity of 72 amps for motor control applications
• 400V AC 3-phase input with 540V DC capability
• Embedded I/O for direct control system integration
• Dynamic braking transistor for controlled motor deceleration
• Three expansion slots for enhanced functionality

Installation and Application Details

• Vertical panel mount design for standard cabinet installation
• Frame 4 construction for compact space utilization
• Open type enclosure for flexible installation options
• Three option slots for safety, feedback, and communication modules
• CM jumper pre-installed for standard operation
• Filtered design for electromagnetic compatibility

Electrical and Environmental Specifications

• 400V AC 3-phase input voltage class
• 540V DC capability for flexible power options
• Air cooled thermal management for reliable operation
• Embedded control I/O for reduced external components
• Robust 27.22 kg construction for industrial durability
• Open enclosure design for accessible maintenance

Packaging and Delivery Information

• Includes one complete Allen-Bradley 20F11NC072JA0NNNNN AC drive
• Professional protective packaging ensures safe delivery
• Global shipping available via FedEx, UPS, or DHL carriers
• All necessary mounting hardware included

Frequently Asked Questions (FAQ)

• What is the power rating?
  The 20F11NC072JA0NNNNN is rated 37 kW normal duty.
• What is the current capacity?
  72 amps continuous current rating.
• What input voltage does it require?
  400V AC 3-phase input with 540V DC capability.
• How is it mounted?
  Vertical panel mount orientation.
• Does it include dynamic braking?
  Yes, with dynamic braking transistor included.
• What frame size is it?
  Frame 4 construction for compact installation.
