RTAC-03 ABB | TTL Pulse Encoder Interface Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

🔄 TTL Pulse Encoder Interface Module (RTAC-03)

Dimensions: 34 x 95 x 20 mm

Mounting: RMIO board or AIMA-01 adapter

Protection: IP20

⚙️ Hardware

Node ID: 16-31 (Rotary switch)

Connectors: 38-pin bus, non-detachable terminal blocks

📊 Encoder Interface

Type: TTL incremental encoder (5V/10-30V)

Output: 5.5V DC (300 mA) or 24V DC (210 mA)

Max Frequency: 200 kHz

⚡ Digital Inputs

Logic Level: 24V (0 = < 5V, 1 = > 15V)

Power Consumption: 150 mA (5V) + 300 mA (24V)

🛠️ Compliance

UL/CSA-approved materials

Complies with EN 50081-2 and EN 50082-2
