SC520 Submodule Carrier CPU ABB MB300 System

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (13 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

ABB SC520 Submodule Carrier with Local CPU – Technical Overview

  • Power consumption: 5 V DC at 1.5 A and 24 V DC at 0.006 A.
  • Total power dissipation: Only 0.8 W, very energy efficient.
  • Physical dimensions: 291 mm depth, 300 mm height, 30 mm width.
  • Net weight: 0.742 kg, suitable for modular racks.
  • Environmental compliance: RoHS (2011/65/EU) and WEEE Category 5.
  • SCIP number: 5b776851-d19c-4e53-a7f4-f02baf230861 (Sweden).

Product Specifications & Compatibility

  • Brand: ABB – a global leader in industrial automation.
  • Model: SC520
  • Type: Communication submodule carrier with local CPU.
  • Supported protocols: MB300 and MB300E for robust networking.
  • System use: Works with AC460, S800 I/O, and other ABB systems.
  • CPU function: Handles local processing and error detection.
  • HS code: 85389091 – parts for electrical apparatus.

Error Codes & Diagnostics

  • The SC520 provides clear error codes for troubleshooting.
  • Error 01: Failed to initialize – check power and backplane.
  • Error 03: Board has halted – restart or replace the unit.
  • Error 04: Board missing or not accessible – verify physical installation.
  • Monitor these codes via the controller interface.

Environmental & Compliance Details

  • RoHS status: Fully compliant with EU Directive 2011/65/EU.
  • WEEE category: Small equipment (external dimension ≤ 50 cm).
  • Battery content: Zero batteries inside the unit.
  • Temperature range: Designed for industrial environments (0–60 °C).
  • Humidity tolerance: 5–95 % non-condensing.
  • Marine version: See SC520M (3BSE016237R1) for coated units.

Frequently Asked Questions (FAQ)

  • Is the SC520 a new original ABB part?
    Yes, we supply only brand new, original ABB SC520 units.
  • Do you have the SC520 in stock?
    Yes, we keep the SC520 in stock for immediate orders.
  • How long does delivery take?
    We ship within 5 days after order confirmation.
  • Which carriers do you use for shipping?
    We use DHL, FedEx, and UPS for fast and reliable delivery.
  • Can I return the SC520 if it doesn't fit?
    Yes, we accept returns within 30 days from delivery.
  • What does error 01 mean on the SC520?
    It means the board failed to initialize – check the power supply.
  • Does this carrier support MB300E protocol?
    Yes, the SC520 fully supports both MB300 and MB300E.
  • Is there a marine-coated version available?
    Yes, see the SC520M (3BSE016237R1) for marine environments.
