Schneider AS-BDEP-210 Modicon 8-Point 120VAC Input Module

Schneider Electric Modicon AS-BDEP-210 Discrete Input Module Overview

Key Technical Specifications

• Manufacturer: Schneider Electric, part of the Modicon product line.
• Product Type: Discrete input module for industrial automation applications.
• Input Points: Features 8 input points for monitoring discrete signals.
• Input Voltage: Operates at 120 VAC for standard industrial power systems.
• Input Frequency: Supports both 50 Hz and 60 Hz power frequencies.
• Isolation: Includes isolated inputs to minimize electrical interference.
• Build Design: Compact form factor suitable for space-constrained installations.
• Product Weight: Weighs only 0.63 lbs (0.28 kg) for easy handling.
• Physical Dimensions: Measures 180 mm length, 160 mm width, and 211 mm height.
• Imperial Size: Converts to 7.1 x 6.3 x 8.3 inches for reference.

Electrical and Operational Characteristics

• Input Type: Accepts discrete AC input signals from field devices.
• Input Response: Provides fast response for real-time control applications.
• Noise Immunity: Isolated design reduces impact of electrical noise.
• Compatibility: Works with Modicon PLC systems for unified control.
• Mounting Style: Installs directly into Modicon I/O racks and backplanes.
• Field Wiring: Accepts standard 120 VAC field device connections.
• Status Indication: Likely includes LED indicators for each input point.
• Environmental Rating: Suitable for typical industrial control cabinet environments.

Frequently Asked Questions (FAQ)

• What is the AS-BDEP-210 module used for?
  The AS-BDEP-210 monitors 8 discrete 120 VAC input signals in Modicon systems.
• How many input points does this module have?
  It features 8 isolated input points for field device connections.
• What voltage does the AS-BDEP-210 require?
  It operates at 120 VAC input voltage at either 50 Hz or 60 Hz.
• Is the AS-BDEP-210 isolated from interference?
  Yes, it includes input isolation to reduce electrical noise effects.
• What are the dimensions of this module?
  It measures 180 x 160 x 211 mm (7.1 x 6.3 x 8.3 inches).
• Do you have the AS-BDEP-210 in stock?
  Yes, we have brand new original units available for immediate shipment.
• How do you ship the AS-BDEP-210?
  We ship globally via FedEx, UPS, or DHL within 5 business days.
• Can I return this module if it doesn't meet my needs?
  Yes, we offer a 30-day return policy from the delivery date.
