Schneider Electric 140AVO02000C Analog Output Module

High-Precision Analog Output for Modicon Quantum Systems

Add versatile and precise control to your automation architecture with the Schneider Electric 140AVO02000C analog output module. Part of the renowned Modicon Quantum series, this module delivers four independent channels of high-accuracy current output. It is engineered for applications demanding fine control and reliable signal integrity over long distances.

Core Technical Specifications

• Brand & Manufacturer: Schneider Electric
• Product Line & Model: Modicon Quantum / 140AVO02000C
• Type: Analog Output Module
• Output Channels: 4 Independent Channels
• Output Type & Range: Current, -10 mA to +10 mA
• Resolution: 12 Bits
• Linearity (Precision): ±1 LSB (Least Significant Bit)
• Update Time: 3 ms
• Source Resistance: 0.1 Ohm
• Max Cable Distance: 400 meters
• Channel Isolation: 500 V for 1 minute

Electrical and System Requirements

• Bus Current Requirement: 700 mA
• Max Power Dissipation: 4.5 W
• Fuse Rating: 0.063 A
• Addressing Requirement: 4 Output Words
• Compliance Marking: CE
• EAN Code: 3595861136182
• Module Weight: 0.3 kg

Key Features and Benefits

• Four-Channel Flexibility: Control multiple actuators or devices independently from a single, compact module.
• High-Resolution Output: 12-bit resolution provides fine control granularity for precise analog signal generation.
• Bipolar Current Range: The -10 mA to +10 mA output supports a wide variety of industrial control applications.
• Excellent Signal Integrity: Low source resistance (0.1 Ohm) and support for long cable runs (400 m) ensure accurate signal delivery.
• Built-in Safety & Isolation: 500V channel isolation protects against cross-talk and surges, enhancing system reliability.
• Fast System Response: A rapid 3 ms update time allows for dynamic control in fast-paced automation processes.

Integration and Wiring Guidelines

• Plan for four output words in your Quantum PLC's I/O addressing scheme for this module.
• Ensure the backplane can supply the required 700 mA of bus current for proper operation.
• Utilize the full 400-meter cable distance capability for remote actuator control when needed.
• Adhere to the 500V isolation rating when designing systems to prevent inter-channel interference.
• Install the specified 0.063A fuse in the associated circuit for enhanced electrical protection.
• The module's low power dissipation (4.5W max) minimizes heat generation in the control cabinet.

Frequently Asked Questions (FAQ)

• What is the output signal type of the 140AVO02000C?
  This module provides a current output signal, configurable in the range of -10 mA to +10 mA per channel.
• How many devices can I control with one module?
  The 140AVO02000C has four isolated output channels, allowing you to control four separate analog devices or loops.
• What does "12-bit resolution" mean for performance?
  It means the output current can be set with 4096 (2^12) discrete steps, enabling very precise analog control.
• Is this module suitable for long-distance wiring?
  Yes, it is designed to support signal cables up to 400 meters long without significant signal degradation.
• What is the purpose of the 500V channel isolation?
  It electrically separates each output channel, preventing fault propagation and ensuring accurate, independent control of each channel.
• How fast can the module update its output values?
  The module updates all its outputs within a fast 3-millisecond cycle time, suitable for most real-time control applications.
