Schneider Electric 140CPS41400C Power Supply Module

Reliable Backplane Power for Modicon Quantum Systems

Ensure stable and protected power for your critical automation rack with the Schneider Electric 140CPS41400C power supply module. Designed for the Modicon Quantum series, this unit converts a 48-60VDC input to a precisely regulated 5.1VDC output. It delivers reliable power for system logic and I/O modules with built-in safety features and flexible, summable current output.

Core Technical Specifications

• Brand & Manufacturer: Schneider Electric
• Product Line & Model: Modicon Quantum / 140CPS41400C
• Type: DC/DC Power Supply Module
• Input Voltage: 48 – 60 V DC
• Output Voltage: 5.1 V DC
• Output Current: 8 A (Summable Configuration)
• Rated Power: 15.6 W
• Input Current: ≤ 3.8 A
• Protections: Internal Overvoltage & Overload Protection
• Fuse: 2 A Time-Lag

Electrical Performance & Features

• Inrush Current: 14 A @ 40 V
• Input Hold-up Time: 13 ms @ 48 V
• Alarm Output: 1 Normally Closed (NC) Contact, 6 A @ 220 V rating
• Local Status Indicator: 1 Green LED (PWR OK)
• Configuration: Output Current is Summable with other units
• Format: Standard Quantum Module
• EAN Code: 3595861137165

Key Features and Benefits

• Wide Input Voltage Range: Operates reliably from 48 to 60VDC, accommodating common industrial DC power sources.
• Summable Output Current: The 8A output can be combined with other 140CPS41400C modules to meet higher backplane power demands.
• Comprehensive Protection: Internal overvoltage and overload safeguards protect both the supply and the connected Quantum modules.
• System Reliability: The 13ms hold-up time at 48V bridges brief input interruptions, preventing system resets.
• Integrated Alarm Signaling: The NC alarm contact provides a dry signal for remote monitoring of power supply status.
• Clear Local Indication: The green PWR OK LED offers immediate visual confirmation of proper operation.

Installation and Application Notes

• Ensure the input DC source (48-60VDC) is stable and can deliver up to 3.8A input current.
• Install the specified 2A time-lag fuse on the input line for branch circuit protection.
• For systems requiring more than 8A, multiple 140CPS41400C modules can be configured in parallel for summable current output.
• Connect the alarm output (NC contact) to your control system for remote fault monitoring and alerting.
• Mount the module in a well-ventilated area within the Quantum rack, respecting standard module spacing.
• Use the green PWR OK LED for quick visual diagnostics during startup and maintenance.

Frequently Asked Questions (FAQ)

• What is the primary purpose of this module?
  The 140CPS41400C provides clean, regulated 5.1VDC power to the backplane of a Modicon Quantum PLC rack for CPU and I/O module operation.
• What does "summable output" mean?
  It means you can install multiple 140CPS41400C power supplies in the same system. Their output currents add together to support racks with higher power requirements.
• What protections does it have?
  The module features internal overvoltage protection (OVP) and overload protection (OLP) to ensure safe operation.
• How is a power failure indicated?
  Locally by the green LED turning off. Remotely via the alarm module's Normally Closed (NC) contact, which will change state.
• What is the hold-up time, and why is it important?
  The 13ms hold-up time is the duration the output remains within specification after input power fails. It helps prevent the PLC from restarting during very brief power glitches.
• Can I use this with a 24VDC source?
  No. The 140CPS41400C requires an input voltage between 48 and 60 Volts DC for proper operation.
