Schneider Electric 140XTS01212 | CableFast System Power Cable

Modicon Quantum 140XTS01212 CableFast High-Power System Cable

The 140XTS01212 is a specialized high‑power system cable from Schneider Electric's Modicon Quantum platform. This CableFast accessory provides reliable power distribution and signal transmission between Quantum modules and peripheral devices. Its pre‑terminated design ensures quick installation and consistent performance.

Product Identification

• Brand & Manufacturer: Schneider Electric / Modicon
• Model Number: 140XTS01212
• Product Range: Modicon Quantum automation platform
• Accessory Type: High‑power system cable
• Accessory Category: Connection and wiring accessories
• Primary Destination: Quantum I/O modules and systems

Cable Specifications

• Cable Length: 12.1 feet (3.7 meters) total length
• Power Rating: High‑power capacity design for demanding applications
• Cable Construction: Pre‑terminated, factory‑assembled cable assembly
• Connector Types: 1 Quantum I/O connector and 1 SUB‑D 50‑pin connector
• Wire Gauge: 16‑18 AWG power conductors with appropriate signal wires
• Insulation Rating: 300V minimum, 80°C temperature rating
• Shielding: Overall foil and braid shield for EMI/RFI protection
• Cable Color: Standard black outer jacket
• Bend Radius: Minimum 10× cable diameter for proper installation

Electrical Characteristics

• Voltage Rating: 300V AC/DC maximum working voltage
• Current Capacity: Up to 10A per power conductor
• Contact Resistance: < 20mΩ per contact (new condition)
• Insulation Resistance: > 100MΩ at 500V DC
• Dielectric Withstanding Voltage: 1500V AC for 60 seconds
• Signal Integrity: Suitable for digital and analog signals up to 1 MHz

Physical & Packaging Details

• Package Weight: 3.757 pounds (1.704 kilograms)
• Package Dimensions: 15.35 × 13.78 × 3.54 inches (39 × 35 × 9 cm)
• Cable Diameter: Approximately 0.5 inches (12.7 mm)
• Connector Material: High‑impact plastic with metal shell
• Contact Material: Gold‑plated copper alloy for reliable connections
• Strain Relief: Integrated strain relief at both connectors

Environmental Specifications

• Operating Temperature: -25°C to +70°C (-13°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity Range: 5% to 95% non‑condensing
• Flame Rating: UL‑recognized flame‑retardant materials
• Chemical Resistance: Resistant to oils and industrial chemicals

Installation & Application

• Compatible Systems: Modicon Quantum 140 series I/O modules
• Installation Time: Significantly reduced compared to field wiring
• Error Reduction: Pre‑terminated design eliminates wiring mistakes
• Main Applications: Factory automation, process control, power distribution systems
• Installation Note: Ensure proper connector alignment before mating

Packaging & Shipping

• Condition: New, factory‑original in sealed packaging
• Packaging: Individual polybag with part number labeling
• Shipping: Available via DHL, FedEx, or UPS with tracking
• Quantity: Sold as single cable unit

Frequently Asked Questions

• What is CableFast technology? It's Schneider Electric's pre‑assembled cable system for faster, more reliable installations.
• Can this cable be used outdoors? It's designed for indoor industrial use unless specified otherwise.
• Is the length exactly 12.1 feet? Yes, the cable is manufactured to 12.1 feet (3.7m) ±2% tolerance.
