Schneider Electric 170BDM09000 I/O Module

Schneider Electric 170BDM09000 Discrete I/O Module

The Schneider Electric 170BDM09000 is a compact discrete I/O module. It provides basic input sensing and output control for small-scale automation applications.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170BDM09000
• Product Series: Modicon Momentum
• Module Type: Discrete Input/Output Module
• Input Channels: 4 discrete inputs
• Output Channels: 2 digital outputs
• Installation Feature: Prewiring support
• Operating Temperature: 0°C to 40°C
• Operating Humidity: Up to 80% RH (non-condensing)
• Operating Environment: Clean indoor area, free of corrosive chemicals
• Maximum Altitude: 1000 meters for operation and storage
• Weight: 0.38 lbs (0.17 kg)

Installation & Wiring

• Mount the module on a standard DIN rail within your control panel.
• Connect up to 4 field input devices like push buttons or limit switches.
• Connect up to 2 output loads such as indicator lamps or small relays.
• Utilize the prewiring feature to prepare connections before final installation.
• Ensure the installation site is clean, dry, and within the temperature/humidity limits.

Packaging & Shipping

• Includes one Schneider Electric 170BDM09000 I/O module.
• All necessary mounting hardware is provided.
• We ship orders globally via FedEx, UPS, and DHL.
• You will receive a tracking number once your order ships.

Frequently Asked Questions (FAQ)

• What is the I/O configuration? It has 4 discrete inputs and 2 digital outputs.
• What does "prewiring support" mean? It allows you to wire the module before mounting it on the rail.
• What is the operating temperature range? It functions from 0°C to 40°C.
• What type of environment is it for? It is designed for clean, indoor industrial environments only.
• What is the altitude rating? It can be used at altitudes up to 1000 meters.

Applications

• Simple machine control for startups, stops, and status indication.
• Adding basic I/O points to an existing Modicon Momentum system.
• Small automation tasks, pilot projects, or educational setups.
• Applications where space is limited and only a few I/O points are needed.
