Schneider Electric 170XTS00701 Busbar Connector

Schneider Electric 170XTS00701 Busbar Connector

The Schneider Electric 170XTS00701 is a single-row busbar connector. It provides reliable power distribution and connection for Modicon Momentum I/O base units.

Technical Specifications

• Manufacturer & Model: Schneider Electric | 170XTS00701
• Product Series: Modicon Momentum
• Device Type: 1-Row Busbar Connector
• Terminal Type: Spring-Type Terminals for easy wiring
• Compatibility: Discrete and Analog I/O Base Units
• Mounting: Plug-In Design
• Construction: High-Conductivity Metal
• Electrical Performance: Low-Resistance, reliable connections
• Operating Temperature: -25°C to +70°C
• Mechanical Durability: Vibration-Resistant design

Installation & Wiring

• Plug the connector directly into the designated slot on the Momentum I/O base.
• Use the spring-type terminals to connect your power supply wires quickly and securely.
• This connector distributes power to all modules on the I/O base unit.
• Ensure all connections are tight and the operating environment is within the temperature range.

Packaging & Shipping

• Includes one Schneider Electric 170XTS00701 busbar connector.
• We ship orders globally via FedEx, UPS, and DHL.
• Tracking information is provided for every shipment.

Frequently Asked Questions (FAQ)

• What is the purpose of this connector? It distributes power to the I/O modules mounted on a Modicon Momentum base unit.
• What type of terminals does it use? It features user-friendly spring-clamp terminals.
• What is it compatible with? It is compatible with Momentum discrete and analog I/O base units.
• How is it installed? It simply plugs into the base unit; no tools are needed for the initial connection.
• What is the temperature rating? It operates from -25°C to +70°C.

Applications

• Essential component for building a complete Modicon Momentum I/O station.
• Provides the main power connection for a group of I/O modules on a single base.
• Used in control panels for machine automation, process control, and building management.
• Simplifies wiring and saves space compared to individual power connections.
