Schneider Electric ABFM04S201 2m Cable for 140ACO02000

Schneider Electric ABFM04S201 Cabled Connector

The ABFM04S201 is a specialized cabled connector from Schneider Electric, designed as an accessory for the Modicon Quantum automation platform. This pre-wired cable provides a ready-to-use connection for analog output signals between Quantum modules and field devices.

Technical Specifications

• Brand & Model: Schneider Electric ABFM04S201
• Product Type: Pre-wired Cabled Connector
• System Platform: Modicon Quantum PLC Accessory
• Compatible Module: Designed for use with the 140ACO02000 Analog Output Module
• Number of Channels: 4 independent analog output channels
• Cable Length: 6.6 feet (2.0 meters)
• Connector Type: SUB-D (D-subminiature) male or female connector
• Number of Ways/Pins: 25-pin configuration

Electrical & Physical Characteristics

• Signal Type: Analog output voltage or current signals
• Wire Gauge: AWG 24
• Wire Cross-Section: 0.22 mm² (0.0003 in²)
• Cable Construction: Multi-conductor, shielded for noise immunity
• Insulation Material: PVC (Polyvinyl Chloride)
• Current Rating: 1 Ampere per conductor
• Voltage Rating: 250 Volts
• Net Weight: 0.45 kg (0.99 lb)

Environmental Specifications

• Operating Temperature: -20 °C to +60 °C (-4 °F to +140 °F)
• Suitable for a wide range of industrial indoor environments

Function & Application

• Provides a direct, pre-terminated wiring solution between a Quantum analog output module and a control device (e.g., valve positioner, drive)
• Eliminates the need for manual wire termination into the module's terminal block, saving installation time
• The 4-channel capacity matches a standard 4-channel Quantum analog output module
• The SUB-D connector is a common industrial interface for analog signals

Packaging & Shipping

• Unit Package (PCE): 1 cabled connector per box.
• Package Dimensions: 25.0 cm L x 24.0 cm W x 6.0 cm H (9.8" x 9.4" x 2.4").
• Package Weight: 426.0 g (15.03 oz).
• Worldwide express shipping via FedEx, UPS, and DHL available.

Frequently Asked Questions (FAQ)

• What Quantum module is this cable for? It is specifically designed for the Schneider Electric 140ACO02000 4-channel analog output module.
• What signals does it carry? It is wired to carry the four analog output signals (typically 0-10V, 0-20mA, or 4-20mA) from the module to your field devices.
• What is on the other end of the cable? The product description specifies one SUB-D connector. The other end typically has individual wires or ferrules for connection to the field device. Check the product image or datasheet for the exact configuration.
• What is the advantage of a pre-wired cable? It ensures correct pinout, reduces wiring errors, saves significant installation time, and provides a neat, professional connection.
• Can it be used with other modules? It is engineered for the 140ACO02000. Using it with other modules may not match the pinout and could cause malfunction.
• What does "25 ways" mean? It means the SUB-D connector has 25 pins. Not all pins may be used; the wiring is configured for the 4 analog outputs and likely common/shield connections.
• Is the cable shielded? Typically, yes. Multi-conductor cables for analog signals are usually shielded to protect against electromagnetic interference (EMI).
