Schneider Electric TSXPBY10 Profibus-DP Module

Schneider Electric TSXPBY10 Profibus-DP Option Module

The TSXPBY10 module from Schneider Electric provides robust Profibus-DP connectivity for Modicon Premium PLC systems. This option module enables high-speed data exchange with field devices in industrial automation networks.

Technical Specifications

• Brand & Model: Schneider Electric TSXPBY10
• Module Type: Profibus-DP Option Module for TSX Micro PLCs
• Compatibility: Designed for integration with Modicon Premium PLC platforms
• Transmission Rate: Configurable from 9.6 Kbit/s up to 12 Mbit/s
• Maximum Segment Length: Up to 1200 meters at 9.6 Kbit/s baud rate
• Network Capacity: Supports up to 124 slave devices when using repeaters
• I/O Data Capacity: 4096 digital inputs and 4096 digital outputs

Electrical & Power Specifications

• Power Supply: 5 V DC provided directly from the PLC rack's power supply
• Current Consumption: 400 mA on the 5 V DC rail
• Connection: Integrates seamlessly into the TSX Micro PLC backplane
• No external power adapter required for standard operation

Environmental Durability

• Operating Temperature: 0 °C to +60 °C (32 °F to 140 °F)
• Storage Temperature: -25 °C to +70 °C (-13 °F to 158 °F)
• Humidity Range: 30% to 95% relative humidity (non-condensing)
• Operating Altitude: Up to 2000 meters (6562 feet) above sea level
• Designed for reliable performance in harsh industrial environments

Robustness & Immunity

• Vibration Immunity: Complies with IEC 68-2-6 standard for industrial vibration
• Shock Immunity: Meets IEC 68-2-27 requirements for mechanical shock
• ESD Protection: Electrostatic discharge immunity per IEC 1000-4-2 standard
• Built to withstand typical electromagnetic interference in factory settings

Network Performance & Configuration

• Flexible baud rate selection optimizes speed versus distance for each application
• Large I/O mapping capacity handles complex automation and control tasks
• Extensive slave device support enables comprehensive fieldbus networks
• Simple configuration through standard PLC programming software

Packaging & Shipping

• The TSXPBY10 module is shipped as one complete unit.
• Standard industrial packaging ensures safe delivery.
• Global shipping available via reliable carriers including FedEx, UPS, and DHL.
• Fast dispatch from our warehouse for quick project integration.

Frequently Asked Questions (FAQ)

• What is the main function of this module? It adds Profibus-DP master functionality to Modicon Premium PLCs for connecting sensors, drives, and other field devices.
• What is the maximum cable length? You can achieve up to 1200 meters at the lowest baud rate of 9.6 Kbit/s. Length decreases as speed increases.
• Does it require external power? No, it draws all required power (5V DC, 400 mA) from the PLC rack's internal supply.
• How many devices can I connect? The network can support up to 124 slave devices when using appropriate repeaters.
• What software is needed for configuration? Use Schneider Electric's standard PLC programming software, such as Unity Pro, for setup and configuration.
• Is it suitable for harsh environments? Yes, with its wide temperature range and compliance with key IEC immunity standards, it is built for industrial use.
