Allen-Bradley 1771-IG TTL Input Module

Core Specifications

8-channel TTL-compatible DC input module

Operating voltage: 5.0–5.3V DC (strict tolerance)

Ultra-fast response: <1ms ON delay

Low power: 122mA backplane current

Weight:0.8kg

Optical isolation for noise protection

Works with PLC-5 series processors

Key Features

TTL/BCD encoder interface support

1771-WC swing-arm wiring (no disassembly needed)

Front-panel LED status indicators

Conformal coating for durability

Supports ½, 1, and 2-slot addressing

Industrial Use Cases

Precision CNC machine feedback signals

Robotic arm position sensors

Laboratory test equipment interfaces

High-speed packaging line counters

Semiconductor manufacturing tools

Installation Notes

Requires 5V DC external power supply

Mount in 1771 I/O chassis (slots 34-36 or 4-6)

Do not connect AC voltage—TTL only

Use shielded cables for noise-sensitive applications

Power off PLC before module installation

Package Includes

1771-IG module

Compatible wiring arm (1771-WC)

Installation manual

12-month manufacturer warranty
