TU843 ABB 3BSE021443R1 Redundant Terminal Block

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (97 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

🛠 Technical Specifications

Product Information

Parameter Specification
Brand ABB
Model TU843
Article Number 3BSE021443R1
Series Advant-800xA
Connection Type Terminal Block (16 Channels)
Voltage 50 V
Current per I/O Channel 3 A
Max Current (Process Connection) 10 A
Process Power 20 V (0V to 20V)
Mounting Orientation Vertical
Stripping Length 7 mm
Wire Size (Solid) 0.2 mm² to 4 mm²
Wire Size (Stranded) 0.2 mm² to 2.5 mm² (24-12 AWG)
Recommended Torque 0.5 Nm to 0.6 Nm
Dielectric Test Voltage 500 V AC
Pollution Degree Degree 2 (IEC 60664-1)
Temperature (Operating) 0°C to +55°C (32°F to +131°F)
Temperature (Storage) -40°C to +70°C (-40°F to +158°F)
Relative Humidity 5% to 95%, non-condensing
Protection Class IP20 (IEC 60529)
Weight 0.6 kg (1.3 lbs)
Width 131 mm (5.16”)
Depth 64 mm (2.52”)
Height 186.5 mm (7.34”)
Mechanical Operating Conditions IEC/EN 61131-2
EMC Compliance EN 61000-6-4, EN 61000-6-2
Overvoltage Categories IEC/EN 60664-1
RoHS Compliance Yes, compliant with EN 50581:2012
WEEE Compliance DIRECTIVE/2012/19/EU
