1769-OA16 Compact I/O Module | Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

Sobre o Produto

1769‑OA16/A (16‑Point AC Output Module)

Electrical Performance

Nominal Voltage: 120 VAC or 240 VAC

Off‑State Leakage: 2.0 mA @132 VAC; 2.5 mA @265 VAC

Surge Current: 5 A for 25 ms, repeatable every 2 s

Max On‑State Drop: 1.5 V peak @2 A

Channel Load: 0.25 A @60 °C; 0.50 A @30 °C

Module Load: 2.0 A @60 °C; 4.0 A @30 °C

Update Delay: ½ cycle (~8.3 ms) ON/OFF

Backplane Draw: 225 mA @5.1 VDC

Mechanical & Environmental

Dimensions: 118 × 35 × 90 mm

Weight: 0.61 lb (0.28 kg)

Temp Range: –20 °C to +60 °C (operating)

Humidity: 5 %–95 % RH non‑condensing

Vibration: 5 g @10–500 Hz (operating)

Shock: 30 g panel mount; 20 g DIN rail

Isolation: 265 VAC basic; 150 VAC reinforced

MTBF: 150 000 hours

Installation & Compatibility

Mounting: 1.5‑slot width, DIN rail or panel

Wire: 22–14 AWG solid; 22–16 AWG stranded

Max Distance: Supports up to 8 modules per power supply

Compatible Power Modules: 1769‑PA2, PB2, PA4, PB4

Lifecycle: Rated for 10 million operations
