1756-IA16I | ControlLogix AC Input Module

Allen-Bradley 1756-IA16I ControlLogix AC Input Module

Key Features

16 isolated AC input channels for industrial control systems. Works with 120V AC signals. Easy installation in ControlLogix chassis.

Technical Specifications

Input voltage range: 79-132V AC

Frequency range: 47-63 Hz

On-state current: 5-15 mA

Response time: 9-18 ms programmable

Power consumption: 4.9W max

Operating temperature: 0-60°C

Isolation: 1500V AC between channels

Module Variants

1756-IA16I/A - Standard version

1756-IA16I/B - Extended temperature range

1756-IA16I/C - High-density version

Installation Guide

Fits any ControlLogix chassis slot

Requires 1756-TBCH terminal block

Tool-free installation

Front LED indicators for status

Compatibility

Works with all ControlLogix processors

Compatible with Studio 5000 software

Supports remote I/O configurations

Industrial Applications

Motor status monitoring

Conveyor belt controls

Pump system diagnostics

HVAC equipment monitoring

Lighting control systems

Problem Solving

Eliminates ground loop issues with isolated inputs

Reduces wiring complexity in high-voltage systems

Provides reliable AC signal detection

Prevents false triggers from electrical noise

Shipping Information

Fedex 2-day delivery available

UPS ground shipping option

DHL express international

Same day dispatch for orders before 3PM

Package Includes

1756-IA16I module

Installation guide

Mounting screws

Front label sheet
