Allen-Bradley 1756-PA50 ControlLogix Power Supply

Power Specifications

• Input Voltage: 85-265V AC (47-63Hz)

• Output Power: 50W @60°C / 60W @50°C

• Current Capacity: - 8A @5.1V (50°C) - 6A @5.1V (60°C) - 2.5A @24V (50°C) - 2A @24V (60°C)

Physical Details

• Dimensions: 5.51 x 3.07 x 5.71 inches

• Weight: 1.7 lbs (0.77 kg)

• Mounting: Left-side chassis slot

• Wire Requirement: 14 AWG copper (90°C min)

Performance Features

• Hold-up Time: 30-40ms

• Isolation Voltage: 250V continuous

• Max Inrush Current: 30A

• Reinforced insulation

Chassis Compatibility

• 1756-A4/A7/A10/A13/A17

• Compatible with Series A, B, and C

• Local or distributed I/O racks

Environmental Ratings

• Operating Temp: 0-60°C (32-140°F)

• Storage Temp: -40-85°C (-40-185°F)

• Humidity: 5-95% non-condensing

• Shock/Vibration resistant

Industrial Applications

• Factory automation systems

• Process control cabinets

• Machine control centers

• Distributed I/O installations

• Manufacturing power distribution

Package Includes

• 1756-PA50 power supply unit

• Installation documentation

• 12-month manufacturer warranty
