AC Voltage Input Module - IC694MDL260 GE Fanuc

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

O Produkcie

IC694MDL260 Key Electrical Specifications:

Nominal Input Voltage: 120 VAC

Input Voltage Range: 0 to 132 VAC

Input Frequency: 47–63 Hz

Current Per Channel: 7 mA at 120 VAC

On-State Voltage: 70–132 VAC

Off-State Voltage: 0–20 VAC

On-State Current (min): 6 mA

Off-State Current (max): 2.5 mA

Advanced Features:

Input Filter Time: Adjustable from 20 ms to 2540 ms in 20 ms increments

Backplane Current Draw: 220 mA @ 5VDC (all channels active)

Field-to-Backplane Isolation: 264 VAC continuous, 1500 VAC for 1 minute

Operating Temperature Range: 0°C to 50°C (32°F to 122°F)

Max On/Off Response Time: 840 ms

Mechanical & System Integration:

Total Inputs: 32 Discrete Points

Groups: 4 Electrically Isolated (8 inputs each)

Shared Common Reference: Per group (failure isolates the group)

DIP Switch for Filter Configuration: Rear-mounted, for standalone adjustment

Terminal Block: Required for standard and expansion base operations

Lifecycle Status: ActiveStorage Temperature: -40°C to 70°C

Field Diagnostics: Terminal block detection reported to CPU
