Analog Input Module 2MLF-AD16A Honeywell MasterLogic-200

Honeywell 2MLF-AD16A | High-Speed 16-Channel Analog Input Module

Engineered for precision industrial monitoring, the Honeywell 2MLF-AD16A delivers ultra-fast 500μs/channel conversion with ±0.2% accuracy. Perfect for critical process control in harsh environments.

Key Advantages

• 🏭 16 isolated channels for multi-point sensing
• ⚡ Blazing-fast 500μs per channel conversion
• 🎯 Lab-grade accuracy (±0.2% @25°C)
• 🛡️ Rugged design for 0-55°C operation

Precision Performance

• Input Channels: 16 (photo-coupled isolation)
• Conversion Speed: 500 microseconds per channel
• Accuracy:
  • ±0.2% (25±5°C)
  • ±0.3% (0-55°C full range)
• Terminal Points: 32-point screw terminal

Environmental Durability

• Operating Temp: 0-55°C (industrial standard)
• Humidity Range: 5-95% RH (non-condensing)
• Altitude Rating: Up to 2000m
• Contamination: Level 2 protection

System Integration

• Address Assignment: 64 fixed or 16 variable points
• Power Consumption: 330mA @5V DC
• Weight: Only 0.115kg (ultra-light)
• Compatibility: MasterLogic-200 series PLCs

What's in the Box

• 1x 2MLF-AD16A module
• 1x Installation guide
• Mounting hardware

Reliability Guarantee

1-year Honeywell factory warranty against defects.

Industrial Applications

• 📊 Process monitoring in chemical plants
• 🏗️ Equipment condition tracking in manufacturing
• 🌡️ Temperature/pressure measurement systems
