Allen-Bradley - 150HP VFD Drive 20F1AND186AA0NNNNN

Allen-Bradley PowerFlex 753 Variable Frequency Drive

The 20F1AND186AA0NNNNN is a high-capacity variable frequency drive from Allen-Bradley's PowerFlex 753 series. This drive provides powerful motor control for demanding industrial applications. It offers substantial output capacity with advanced control and safety features.

Core Technical Specifications

• Brand & Model: Allen-Bradley 20F1AND186AA0NNNNN (PowerFlex 753 Series)
• Motor Power (ND): 150 Horsepower normal duty
• Motor Power (HD): 125 Horsepower heavy duty
• Output Current: 186 Amps continuous capacity
• Voltage Class: 480 Volts AC three-phase
• Motor Output: 3-phase configuration
• Frame Size: Frame 6 industrial design

Control & Performance Features

• Control Modes: V/Hz and Vector control
• DC Bus Voltage: ~650 Volts DC
• Braking System: Dynamic braking transistor included
• Input Design: AC input with pre-charge
• Control Flexibility: Multiple control options
• Performance: High-performance motor control

Safety & Protection Features

• Safety Features: Safe Torque Off (STO) + speed monitor
• Filtering: Filtered with CM removed
• Electrical Protection: Comprehensive drive protection
• Safety Compliance: Industrial safety standards
• Monitoring: Speed monitoring capability
• Emergency Stop: STO for safe operation

Expansion & Interface Features

• Expansion Slots: 3 available expansion slots
• Local I/O: Built-in input/output capability
• Embedded I/O: Standard interface modules
• System Integration: Easy control system integration
• Future Upgrades: Expansion slot flexibility
• Interface Options: Multiple interface possibilities

Environmental & Physical Specifications

• Enclosure Rating: IP00/IP20 open type
• Cooling Method: Air cooled thermal management
• Operating Temperature: Standard industrial range
• Unit Weight: 49.92 kilograms (110.06 pounds)
• Mounting Style: Open type for panel installation
• DC Terminals: No DC terminals included

Application Features

• High Power Applications: Large motor control needs
• Industrial Processes: Manufacturing and production
• Material Handling: Heavy conveyor systems
• Process Control: Industrial process applications
• Safety Applications: Systems requiring STO protection
• Equipment Drive: Various industrial machinery

Installation Guidelines

• Install in well-ventilated electrical cabinets or enclosures
• Connect 480V AC three-phase power supply
• Ensure adequate space for air cooling circulation
• Follow Allen-Bradley wiring diagrams precisely
• Configure safety features including STO as required
• Verify motor specifications match 186A output rating

Performance Specifications

• Power Capacity: 150HP normal duty, 125HP heavy duty
• Current Rating: 186 Amps continuous output
• Voltage Rating: 480V AC operational voltage
• Control Accuracy: Precise V/Hz and vector control
• Safety Level: STO and speed monitoring
• Reliability: Industrial-grade construction

Packaging & Shipping Information

• Includes one Allen-Bradley 20F1AND186AA0NNNNN drive unit
• Package contains complete installation and operation manuals
• We ship via reliable carriers including FedEx, UPS, and DHL
• Shipping weight: 49.92 kg (110.06 lbs) with protective packaging
• Industrial-grade packaging ensures component protection

Frequently Asked Questions

• What horsepower rating? 150HP normal duty, 125HP heavy duty.
• What output current? 186 Amps continuous output.
• What safety features? Safe Torque Off (STO) + speed monitor.
• How many expansion slots? 3 available expansion slots.
• What is the weight? 49.92 kilograms (110.06 pounds).
