Bently Nevada 3500/22-01-02-02 | Multi-Certified Transient Interface

Core Product Overview

• The Bently Nevada 3500/22-01-02-02 is a Transient Data Interface Module.
• This module captures and transmits machinery transient waveform data.
• It features fiber optic Ethernet and multi-hazardous area certifications.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/22-01-02-02
• TDI Type: 01 = Standard Transient Data Interface
• I/O Module: 02 = 100Base-FX Fiber Optic Ethernet
• Agency Approval: 02 = Multi (CSA, ATEX, IECEx)
• Connectivity: 100Base-FX fiber optic network interface
• Certifications: CSA, ATEX, and IECEx hazardous area approved
• Module Weight: 1.11 Kg total weight

Functional & Communication Features

• TDI Function: Captures transient events and waveform data
• Network Interface: 100Base-FX fiber optic Ethernet port
• Data Transmission: Sends captured data to analysis systems
• Fiber Optic Benefits: EMI immunity, long-distance capability
• Event Capture: Trigger-based data recording
• Applications: Machinery diagnostics and event analysis

Safety & Certification Features

• CSA Certification: Canadian Standards Association approval
• ATEX Certification: European explosive atmosphere compliance
• IECEx Certification: International explosive atmosphere standard
• Hazardous Area: Approved for Class I Zone 1/2 areas
• Global Compliance: Multiple international safety certifications
• Safety Design: Engineered for hazardous location operation

Physical Specifications

• Weight: 1.11 Kg complete module weight
• Mounting: Standard 3500 series rack installation
• Connectors: Fiber optic Ethernet connections
• Construction: Industrial-grade certified components
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available

Ordering & Configuration

• Base Model: 3500/22 TDI Module
• First Option: 01 = Standard TDI Type
• Second Option: 02 = 100Base-FX Fiber Optic Ethernet
• Third Option: 02 = Multi (CSA, ATEX, IECEx) Approval
• Complete Part Number: 3500/22-01-02-02
• Certification: Full hazardous area certification package

Installation & Application

• Install the 3500/22-01-02-02 in a 3500 system rack
• Connect fiber optic Ethernet cable for network communication
• Follow ATEX/IECEx installation guidelines for hazardous areas
• Configure transient data capture triggers and parameters
• Test data transmission to external analysis systems

Packaging & Delivery

• One Bently Nevada 3500/22-01-02-02 TDI Module
• Original factory packaging with complete certification documents
• Shipping via FedEx, UPS, or DHL express international service
• Complete CSA, ATEX, and IECEx certification documentation
• Certificate of Origin available for customs requirements

Frequently Asked Questions

What is the purpose of this TDI module?

The 3500/22-01-02-02 captures and transmits transient waveform data from machinery events.

What type of network connection does it use?

It uses 100Base-FX fiber optic Ethernet for reliable, noise-immune communication.

What hazardous area certifications does it have?

It is certified CSA, ATEX, and IECEx for explosive atmosphere applications.

How does this differ from the 3500/22M model?

This is the standard 3500/22 model with the same fiber optic and certification options.

Where is this product manufactured?

It is manufactured in the United States of America.
