FC-PSU-UNI2450U | Universal Power Supply Unit

Power Specifications

Input Voltage: 110-240 V AC (93-253 V AC range)

Output Voltage: 25V DC or 28V DC selectable

Max Output Current: 48A at 25V DC (43A at 28V DC)

Efficiency: >85% at 240V AC, >80% at 120V AC

Power Factor: Close to 1

Ripple Noise: < 40 mVpp

Physical Specifications

Dimensions: 420.5 × 140 × 90 mm (16.57 × 5.51 × 3.54 in)

Weight: 5.7 kg (12.5 lb) including cables

Operating Temperature: -5°C to +70°C (23°F to 158°F)

Storage Temperature: -25°C to +85°C (-13°F to 185°F)

Connection Details

AC Input: IEC 60320 C20 socket, 16A with clip

DC Output: 2 x Phoenix PCV6-16/2 connectors

Wire Size: 0.75 mm² to 16 mm²

Alarm Contact: 3-pole Phoenix socket, 100 mA / 30 V rating

Safety Features

Certifications: TUV approved

Isolation: 3750 Vrms input to output

Protection: Dual overvoltage protection

Inrush Current: < 15A

Hold-up Time: 100 ms at full load

Applications

Industrial automation systems

Control cabinet power distribution

PLC and motor drive power

Manufacturing equipment

Process control systems

Package Includes

FC-PSU-UNI2450U power supply unit

Complete cable set

Mounting hardware

12-month warranty

Shipping & Support

Available in versions V2.1 and V3.0

In stock for immediate shipment

Worldwide delivery via FedEx, UPS, DHL

24/7 technical support
