Modicon TSXP57453M Advanced Communication PLC

Product Overview: Schneider Electric TSXP57453M PLC

The Schneider Electric TSXP57453M is a high-performance double-format PLC processor. It delivers ultra-fast processing and massive I/O capacity for complex automation systems. This unit excels in demanding industrial control applications.

Core Technical Specifications

• Brand & Model: Schneider Electric TSXP57453M
• Processing Speed: Ultra-fast 0.06 µs Boolean execution time
• I/O Capacity: Massive 2040 discrete I/O and 256 analog I/O points
• System Expansion: Supports up to 16 equipment racks for large systems
• Memory Capacity: 176 Kwords data RAM with PCMCIA card expansion
• Communication: Fipio, CANopen, serial links, and Fieldbus options
• Instruction Rate: 13.82 thousand instructions per ms (100% Boolean)

Performance & Speed Details

• Executes Boolean logic in just 0.06 microseconds per instruction
• Handles word arithmetic in 0.08 µs and floating-point in 1.7 µs
• Maintains 8.8 Kinst/ms with mixed Boolean and arithmetic operations
• System overhead of 0.22 ms (fast task) and 1.15 ms (master task)
• The TSXP57453M offers exceptional processing throughput

Communication & Networking

• Integrated Fipio manager for distributed I/O management
• Non-isolated serial links for legacy device connectivity
• CANopen protocol support for motion control applications
• Compatible with Fieldbus modules and AS-Interface bus systems
• Multiple network module options for flexible architecture

Physical & Environmental Design

• Module Format: Double-format design for expanded capabilities
• Weight: 1.00 lb (0.45 kg) for easy installation
• Current Consumption: Efficient operation at 1080 mA
• LED Indicators: Five status LEDs for RUN, FIP, I/O, ERR, TER
• Protective Treatment: TC coating for industrial environment durability
• Environmental: RoHS compliant for environmental responsibility

Memory & Storage Configuration

• Internal RAM provides 96 Kwords program and data storage
• PCMCIA card expands to 992 Kwords program memory
• Additional 2048 Kwords data storage available via PCMCIA
• Memory configuration flexible for various application needs
• Optimized for both program execution and data logging

Frequently Asked Questions (FAQ)

What makes the TSXP57453M processing speed special?

Its 0.06 µs Boolean execution is among the fastest available, ideal for high-speed control applications.

How many I/O points can this processor handle?

The TSXP57453M manages up to 2040 discrete I/O and 256 analog I/O points for large systems.

What communication protocols are supported?

It supports Fipio, CANopen, serial communications, and various Fieldbus networks.

Can this processor control multiple equipment racks?

Yes, it supports systems with up to 16 racks for distributed control applications.

What is the advantage of the double-format design?

Double-format provides more processing power and expansion capabilities in a single unit.

Is memory expansion possible with this processor?

Yes, via PCMCIA cards that expand program memory to 992 Kwords and data to 2048 Kwords.
